DATALOGIC/DATASENSING Inductive Proximity Sensors | PM3/00-1H
- Sensing range (max.): 2 mm
- Connection type: M12 plug
- Switching output: PNP/NPN
- Output function: NO/NC
- Switching frequency: 1 kHz
- Installation type: Flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
DATALOGIC/DATASENSING Inductive Proximity Sensors | PM3/00-1H
DATALOGIC/DATASENSING Inductive Proximity Sensors
DATALOGIC/DATASENSING Inductive Proximity Sensors supplier in Bangladesh
PM3
Decout sensors: NPN/PNP – NO/NC
- Wide range of models: standard. DECOUT® output
- Output: cable. M12 plug cable exit
- Models with 4 wires
- ATEX models. cat. 3. available on request
- Wide range of models: standard, DECOUT® output
- Output: cable, M12 plug cable exit
- Models with 4 wires
- ATEX models, cat. 3
Technical details-
| Nominal sensing distance | 2mm |
| Operanting distance | 0…1,62mm |
| Standard target | 12x12mm FE360 |
| Correction Factor | copper: 0,30 / aluminium: 0,35 / brass: 0,50 / stainless steel: 0,80 |
| Thermal drift of Sr | < 10% |
| Repeat Accuracy | < 5% (UB 24V Ta=23°C ±5°C) |
| Hysteresis | 1 … 20% |
| Description | M12 standard flush mount |
| Functions | Proximity |
| Output type | NPN/PNP |
| Output Function | NO/NC |
| Switching frequency | 1kHz |
| Operating Voltage | 10…30Vdc |
| No-Load supply current | ≤ 30mA |
| Load current | ≤ 100mA |
| Leakage current | ≤ 10μA |
| Output voltage drop | ≤ 1,2V @100mA |
| Max ripple content | ≤ 10% |
| LED indicators | Yellow LED output state |
| Time delay before availability | ≤100ms |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Impulsive Overvoltage Protection | Yes |
| Protection against inductive loads | Yes |
| Dimensions | M12 x 1 / L = 73,3mm |
| Mounting | Shielded |
| Material | Nickel-plated brass |
| Housing material | Nickel-plated brass |
| Weight | 29g |
| Connections | M12 Plug |
| Active Head Material | PBT |
| Tightening torque | 10Nm |
| Operating temperature | -25°C…+70°C |
| Diameter/Dimension | M12 |
Datasheet: PDF
