DATALOGIC_DATASENSING TL46-W-815-PZ

DATALOGIC/DATASENSING Contrast Sensors TL46-W-815-PZ | Part no: 954600005

  • Sensing range (max.): 12 mm
  • Connection type: M12 plug
  • Output type: PNP/NPN
  • Switching frequency: 15 kHz



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

DATALOGIC/DATASENSING Contrast Sensors TL46-W-815-PZ | Part no: 954600005

DATALOGIC/DATASENSING Contrast Sensors

DATALOGIC/DATASENSING Contrast Sensors Supplier in Bangladesh

TL46

High resolution, White, Red or RGB emission, very high speed and precision with low jitter suited for packaging and synchronization based mark detection in extremely fast processes with IO-Link.

  • Fastest and accurate low jitter model TL46…WH
  • Color mode enhanced model (TL46…WE, TL46…WH)
  • Teach-In. Trimmer. Automatic.Dynamic settings with display
  • Up to 70kHZ switching frequency models
  • IO-Link. NPN/PNP and analog outputs
TL46-W-815-PZ AT A GLANCE
  • Fastest and accurate low jitter model (TL46-WJ)
  • Color mode enhanced model (TL46-WE)
  • Wide-spectrum RGB or white LED emission
  • 5 different models: basic, standard, enhanced, low jitter, color mode
  • Automatic, manual and dynamic settings
  • 10, 15, 20, 30 or 50 kHz switching frequencies
  • Very low jitter down to 7µs (TL46-WJ…)
  • NPN/PNP and analog outputs
  • Standard mounting, M12 connector rotatable to 5 positions

Technical details-

Detection properties
Nominal sensing distance 12mm
Spot dimension 0,8 x 4mm
Sensitivity adjustment Teach-in
Application
Function Principle Contrast mark detection
Description Standard case – vertical spot
Optic position axial
Functions Contrast mark detection
Outputs
Output type NPN/PNP – IO-LINK
Switching frequency 15kHz
Response time 0,02 (25kHz low jitter)
Electrical data
Operating Voltage 10…30VDC
No-Load supply current ≤ 50mA
Load current ≤100mA
Output voltage drop ≤2V
Max ripple content ≤ 2Vpp
LED indicators Yellow (output state) Green (Ready) orange (delay or keylock)
Short-circuit protection YES
Reverse Polarity Protection Yes
Emission LED RGB
Interference to external light according to EN 60947-5-2 : 2020
Impulsive Overvoltage Protection Yes
Insulation resistance >20 MΩ 500 Vdc, between electronics and housing
Contact resistance 500 Vac 1 min., between electronics and housing
Mechanical data
Dimensions 32x60x82
Material
Housing material Metal – Aluminium / Glass
Connections M12 plug
Active Head Material Glass
Storage temperature – 20°C…+70°C
Diameter/Dimension Cubic



Datasheet: PDF

More Contrast sensors :

DATALOGIC/DATASENSING LENS No. 28 glass, DATALOGIC/DATASENSING TL46-WH-815-PZ,  DATALOGIC/DATASENSING TL46-W-815, DATALOGIC/DATASENSING TL46-WE-815, DATALOGIC/DATASENSING TL46-W-815L, DATALOGIC/DATASENSING TL46-WL-815, DATALOGIC/DATASENSING TL46-WL-815L, DATALOGIC/DATASENSING TL46-WLF-815, DATALOGIC/DATASENSING TL46-WLF-815L, DATALOGIC/DATASENSING TL46-W-815G, DATALOGIC/DATASENSING TL46-WE-825, DATALOGIC/DATASENSING TL46-A-415, DATALOGIC/DATASENSING TL46-A-425, DATALOGIC/DATASENSING TL46-A-615, DATALOGIC/DATASENSING TL46-A-625, DATALOGIC/DATASENSING TL46-WJ-815, DATALOGIC/DATASENSING TL46-WJ-815L, DATALOGIC/DATASENSING LENS HI-RES glass, DATALOGIC/DATASENSING LENS No. 22 glass, DATALOGIC/DATASENSING LENS No. 9 PMMA, DATALOGIC/DATASENSING LENS No. 9 glass, DATALOGIC/DATASENSING LENS No. 18 glass, DATALOGIC/DATASENSING LENS No. 40 glass, DATALOGIC/DATASENSING LENS No. 50 glass
