DATALOGIC_DATASENSING IL1_AN-4A

DATALOGIC/DATASENSING Inductive Proximity Sensors | IL1/AN-4A

  • Sensing range (max.): 6 mm
  • Connection type: 2m PVC Cable
  • Switching output: NPN
  • Output function: NO
  • Switching frequency: 3kHz
  • Installation type: Unshielded



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

DATALOGIC/DATASENSING Inductive Proximity Sensors | IL1/AN-4A

DATALOGIC/DATASENSING Inductive Proximity Sensors

DATALOGIC/DATASENSING Inductive Proximity Sensors supplier in Bangladesh

IL1

Cubic inductive sensors: 10 x 28 x 16 mm.

  • Compact dimensions: 10 x 28 x 16 mm
  • Supply voltage 10…30 Vdc. output current 300 mA
  • LED status indicator
  • IP67 housing protection
  • Complete protection against electrical damages

Technical details-

Detection properties
Nominal sensing distance 6mm
Operanting distance 0…4,8mm
Standard target 18x18mm FE360
Correction Factor copper: 0,41 / aluminium: 0,50 / brass: 0,55 / stainless steel: 0,75
Thermal drift of Sr < 10%
Repeat Accuracy < 5% (UB 24V Ta=23°C ±5°C)
Hysteresis 1 … 20%
Application
Description 10,3x28x16mm cubic no-flush mount
Functions Proximity
Outputs
Output type NPN
Output Function NO
Switching frequency 3kHz
Electrical data
Operating Voltage 10…30Vdc
No-Load supply current ≤ 10mA
Load current ≤ 300mA
Leakage current ≤ 0,12mA
Output voltage drop ≤ 1,5V @100mA
Max ripple content ≤ 10%
LED indicators Yellow LED output state
Time delay before availability ≤100ms
Short-circuit protection Yes
Reverse Polarity Protection Yes
Impulsive Overvoltage Protection Yes
Protection against inductive loads Yes
Mechanical data
Dimensions 28 x 16 x 10,3 mm
Mounting Unshielded
Material PA
Housing material PA
Weight 63g
Connections 2m PVC Cable
Active Head Material PA
Operating temperature -25°C…+70°C
Diameter/Dimension 10,3x28x16mm



Datasheet: PDF
