DATALOGIC/DATASENSING Fork Sensors | FC6I/0B-0804-1F
- Sensing range (max.): 80 mm
- Connection type: M8 plug 4pin
- Switching output: NPN / PNP L/D Selectable
- Output function: L/D Selectable
- Switching frequency: 10 kHz
- Slot width: 80 mm
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
DATALOGIC/DATASENSING Fork Sensors | FC6I/0B-0804-1F
DATALOGIC/DATASENSING Fork Sensors
DATALOGIC/DATASENSING Fork Sensors supplier in Bangladesh
FC6
Optical slot sensors with high precision, laser and infrared emission, for detection of objects, labels and trasparent film.
- Simple and accurate adjustment manually by -/+ buttons
- Infrared or LASER emission class 1
- Metal housing
- Light/Dark switching. selectable by button
- Minimum size object detection 0.2 mm (FC6I) and 0.05 mm (FC6L)
- M8 connectors (4 pins): PNP or NPN. LO/DO
- Switching frequency 10 kHz
- Simple and accurate adjustment manually by -/+ buttons
- Infrared emission; LASER emission class 1
- Metal housing
- Light/Dark switching, selectable by button
- Minimum size object detection 0,2 mm (FC6I) and 0,05 mm (FC6L)
- -20…+60 °C temperature range
- M8 connectors (4pins): PNP/NPN, LO/DO
- Switching frequency 10 kHz
Technical details-
| Nominal sensing distance | 80mm |
| minimum detectable object | 0.2mm |
| Sensitivity adjustment | Teach-in |
| Function Principle | Photoelectric slot |
| Output type | NPN / PNP L/D Selectable |
| Output Function | L/D Selectable |
| Switching frequency | 10kHz |
| Response time | 50 µs |
| Operating Voltage | 12…24VDC |
| No-Load supply current | ≤ 40mA |
| Load current | ≤100mA |
| Output voltage drop | ≤2V@Iload=100mA |
| Max ripple content | ≤10% |
| LED indicators | Yellow (status output), Red (adjustment or block keypad) |
| Time delay before availability | ≤200ms |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Emission | LED Infrared |
| Interference to external light | 5000lux (incandescent lamp), 10000lux (sunlight) |
| Dimensions | Width slot detection 80mm – Depth slot detection 42mm |
| Housing material | Painted aluminium |
| Weight | 80g |
| Connections | M8 plug 4pin |
| Active Head Material | Polyamide/glass |
| Operating temperature | – 20°C…+ 60°C |
| Storage temperature | – 30°C…+ 80°C |
| Width slot detection | 80mm |
| Depth slot detection | 42mm |
Datasheet: PDF
