DATALOGIC_DATASENSING AHS_AP-3A

DATALOGIC/DATASENSING Inductive Proximity Sensors | AHS/AP-3A

  • Sensing range (max.): 2 mm
  • Connection type: 2m PVC Cable
  • Switching output: PNP
  • Output function: NO
  • Switching frequency: 7 kHz
  • Installation type: Shielded



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

DATALOGIC/DATASENSING Inductive Proximity Sensors | AHS/AP-3A

DATALOGIC/DATASENSING Inductive Proximity Sensors

DATALOGIC/DATASENSING Inductive Proximity Sensors supplier in Bangladesh

AHS

Miniaturized inductive sensors with ø6.5 mm diameter. Where small spaces required small dimensions.

  • Miniaturized dimensions: Ø6.5 x 20 mm (cable) / 30 mm (plug) lenght
  • Shielded models with sensing distance 1.5 mm / 2 mm
  • Output current: 100 mA
  • ASIC inside: high reliability and repeatibility
  • Totally protected against electrical damages
  • Cable and plug M8 output
  • Stainless steel AISI303 housing

Technical details-

Detection properties

Nominal sensing distance 2mm
Operanting distance 0…1,62mm
Standard target 6,5×6,5mm FE360
Correction Factor copper: 0,05 ± 10% / aluminium: 0,05 ± 10% / brass: 0,10 ± 10% / stainless steel: 0,50 ± 10%
Thermal drift of Sr < 10%
Repeat Accuracy < 5% (UB 24V Ta=23°C ±5°C)
Hysteresis 1 … 20%
Application
Description Ø6,5 mini flush mount
Functions Proximity
Outputs
Output type PNP
Output Function NO
Switching frequency 7kHz
Electrical data
Operating Voltage 10…30Vdc
No-Load supply current ≤ 10mA
Load current ≤ 100mA
Leakage current ≤ 10μA
Output voltage drop ≤ 1,5V @100mA
Max ripple content ≤ 10%
LED indicators Yellow LED output state
Time delay before availability ≤ 50ms
Short-circuit protection Yes
Reverse Polarity Protection Yes
Impulsive Overvoltage Protection Yes
Protection against inductive loads Yes
Mechanical data
Dimensions Ø6,5 / L = 20,3mm
Mounting Shielded
Material AISI303 Stainless Steel
Housing material AISI303 Stainless Steel
Weight 30g
Connections 2m PVC Cable
Active Head Material PBT
Operating temperature -25°C…+70°C
Diameter/Dimension Ø6,5



Datasheet: PDF
