DATALOGIC_DATASENSING FC7I_0N-M304-0F

DATALOGIC/DATASENSING Fork Sensors | FC7I/0N-M304-0F

  • Sensing range (max.): 3 mm
  • Connection type: M8 plug 4pin
  • Switching output: NPN L/D Selectable
  • Output function: L/D Selectable
  • Switching frequency: 10 kHz



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

DATALOGIC/DATASENSING Fork Sensors | FC7I/0N-M304-0F

DATALOGIC/DATASENSING Fork Sensors

DATALOGIC/DATASENSING Fork Sensors supplier in Bangladesh

FC7

Optical fork sensor with high precision, for detection of opaque labels.

  • Dinamic Teach-In or automatic and manual adjustment with “+/-” buttons
  • Minimum object detection 2 mm (gap between labels). 2 mm (label size)
  • Infrared emission
  • Light/Dark switching. selectable by button
  • Switching frequency 10 kHz
  • M8 connectors (4 pins): PNP or NPN. LO/DO selectable

FC7I/0N-M304-0F AT A GLANCE

  • Dynamic Teach-in or control panel and manual adjustment with “+/-” buttons
  • Minimum object detection 2 mm (gap between labels), 2 mm (label size)
  • Infrared emission
  • Light/Dark switching, selectable by button
  • Switching frequency 10 kHz
  • M8 connectors (4 pins): PNP or NPN, LO/DO selectable
  • -20 .. +60 °C temperature range

Technical details-

Detection properties
Nominal sensing distance 3mm
minimum detectable object 2mm
Sensitivity adjustment Teach-in
+/-50 µm a 150m/min +/-50 µm at 150m/min
200 m/min 200 m/min
2mm 2mm
Application
Function Principle Photoelectric slot
Outputs
Output type NPN L/D Selectable
Output Function L/D Selectable
Switching frequency 10Khz
Response time 50 µs
Electrical data
Operating Voltage 12…24VDC
No-Load supply current ≤ 35mA
Load current ≤100mA
Output voltage drop ≤2V@Iload=100mA
Max ripple content ≤10%
LED indicators Yellow (status output), Red (adjustment or block keypad)
Time delay before availability ≤200ms
Reverse Polarity Protection Yes
Emission LED Infrared
Mechanical data
Dimensions Width slot detection 3mm – Depth slot detection 42mm
Housing material PA
Weight 35g
Connections M8 plug 4pin
Operating temperature – 20°C…+ 60°C
Storage temperature – 30°C…+ 80°C
Width slot detection 3mm
Depth slot detection 42mm



Datasheet: PDF

More Fork sensors :

DATALOGIC/DATASENSING FC7I/0B-M304-0F, DATALOGIC/DATASENSING FC7I/0P-M304-0F
