BALLUFF BGL 5H-002-01

BALLUFF Fork Sensors BGL005C | BGL 5H-002-01

  • Functional principle: Through-beam sensor
  • Fork opening: 5 mm
  • Connection type: Cable, 1 m, PVC
  • Switching output: PNP
  • Output function: NO/NC
  • Light type: LED Infrared



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

BALLUFF Fork Sensors BGL005C | BGL 5H-002-01

BALLUFF Fork Sensor

BALLUFF Fork Sensors supplier in Bangladesh

Miniaturized fork sensors

Balluff BGL fork sensors are known for precise object detection. Their comprehensive portfolio scores points with reliable solutions even for difficult and specialized applications. Now they are expanding their range to include particularly compact and versatile sensors for space-critical automation applications.

The new BGL MiniSlot fork sensors from Balluff can be used very flexibly with their different mounting and connection options. The sensors are fully potted, which makes them resistant to vibrations, shocks and other environmental influences, and guarded with a IP64 protection rating. The bright LEDs also indicate the switching status and allow you to accurately read its diagnostics.

With their particularly compact size, the new BGL require significantly less installation space than conventional fork sensors. In addition, six different designs and a wide variety of connection options make the sensors even more flexible to use in a wide range of applications

BALLUFF Fork Sensors at a glance

Special Features

  • Six different designs for flexible use
  • Cost-effective, robust solution for space-critical applications
  • Precise detection and high repeatability
  • Status indication with bright LEDs
  • Unified slot width 5 mm
  • Easy connection with 4-pin M8 plug, flat connector or cable
  • Switching frequency up to 3 kHz for fast processes

Technical details-

Features

Property Value
Dimension 12 x 12 x 13.4 mm
Fork opening 5 mm
Interface
PNP normally closed (NC)


PNP normally open (NO)
Principle of operation Photoelectric sensor
Principle of optical operation Through-beam sensor
Light type LED infrared Infrared
Connection Cable, 1 m, PVC
Housing material PBT
Material sensing surface PMMA
Operating voltage Ub 5…24 VDC
Approval/Conformity CE, cULus, UKCA, WEEE



Datasheet: PDF
