DATALOGIC_DATASENSING S8-PR-5-W03-PP

DATALOGIC/DATASENSING Contrast Sensors S8-PR-5-W03-PP | Part no: 950801060

  • Sensing range (max.): 10 mm
  • Connection type: M8 plug 4pin
  • Output type: PNP L/D selectable
  • Output function: L/D selectable
  • Switching frequency: 10kHz



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

DATALOGIC/DATASENSING Contrast Sensors S8-PR-5-W03-PP | Part no: 950801060

DATALOGIC/DATASENSING Contrast Sensors

DATALOGIC/DATASENSING Contrast Sensors Supplier in Bangladesh

S8

The Compact sensor format to solve challenging applications (target objects that are too small, too fast, too clear, too shiny) performance oriented series available also with AISI316L housing models.

  • Compact dimensions (14 x 42 x 25 mm)
  • Background suppression for transparent and shiny objects
  • Extremely focused spot. under 1 mm with high resolution (LASER model)
  • INOX AISI 316L model
  • Extended IO-Link parametrization with smart task
S8-PR-5-W03-PP AT A GLANCE
  • Compact dimensions (14x42x25 mm)
  • Background suppression for transparent and shiny objects
  • Contrast sensors up to 25 kHz switching frequency
  • Extremely focused spot, under 1 mm (LASER model)
  • Very high resolution LASER models
  • INOX AISI 316L model
  • Extended IO-Link parametrization with counter
  • All output fully PNP/NPN/PP IO-Link configurable
  • IO-link COM2
  • IO-Link dual channel with no jitter addition

Technical details-

Detection properties

Nominal sensing distance 10mm
Sensitivity adjustment Teach-in
Application
Function Principle Contrast mark detection
Description Compact slim case
Optic position Radial 90°
Functions Contrast mark detection
Outputs
Output type PNP L/D selectable
Output Function L/D selectable
Response time 0,05 (10kHz)
Electrical data
Operating Voltage 12…30VDC
No-Load supply current ≤ 30mA
Output voltage drop ≤2V@Iload=100mA
LED indicators Yellow (status output) or (output/alarm) Green (powerON)
Short-circuit protection YES
Reverse Polarity Protection Yes
Emission LED RGB
Interference to external light according to EN 60947-5-2 : 2020
Impulsive Overvoltage Protection Yes
Insulation resistance >20 MΩ 500 Vdc, between electronics and housing
Contact resistance 500 Vac 1 min., between electronics and housing
Mechanical data
Dimensions 14x43x25
Material Plastic – ABS / PMMA
Housing material ABS(Housing), PMMA (Optics)
Connections M8 plug 4pin
Active Head Material PMMA
Storage temperature – 25°C…+70°C
Diameter/Dimension Cubic



Datasheet: PDF
