YASKAWA AC Drive D1000 | CIMR-DC2A0005BAA | 3.7 kW
- Rated output current: 15 A
- Max. applicable motor power: 3.7 kW
- Input power supply: 200 V
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
YASKAWA AC Drive D1000 | CIMR-DC2A0005BAA | 3.7 kW
YASKAWA AC Drive
YASKAWA AC Drive Supplier in Bangladesh
D1000
Regenerative Converter Unit
The Yaskawa D1000 regenerative converter unit saves energy and space. Suitable for both regenerative individual drives and systems of AC drives, servo axes or robots, the D1000 feeds excess braking energy back into the grid instead of converting it into heat. This not only reduces energy consumption and cost but also contributes to the protection of our environment.
- Low energy consumption due to common DC bus systems – the braking energy of one drive is consumed by other drives in the system
- Sinusoidal input current reduces the strain on the power supply system (lines, transformers)
- Less installation space as braking transistors and resistors are not required
- Lowers the total operating costs of the system
Technical Details
| Property | Value |
| Input power supply | 200 V |
| Rated output current (ND) | 15 A |
| Overload Tolerance (ND) | 120 % for 60 s |
| Overload Tolerance (HD) | 150 % for 60 s |
| Max. applicable motor power (ND) | 3.7 kW |
| Input power phases | 3-phase |
| Standards compliance | CE, UL, UKCA |
| Ambient Temperature (Min) | -10 °C |
| Ambient Temperature (Max) | 40 °C |
| Ambient Temperature (Max) with Derating | 50 °C |
| Max. Humidity (non-condensing) | 95 % |
| Max. Altitude (without Derating) | 1000 m |
| Max. Altitude (with Derating) | 3000 m |
| Height | 180 mm |
| Width | 300 mm |
| Depth | 187 mm |
| Weight | 5 kg |
| Cooling method | Air cooling |
| Enclosure | IP20 |
| Environmental Specifications | Standard |
| Analog Input | 3 |
| Analog Output | 2 |
| Digital Input | 8 |
| Digital Output | 4 |
| Torque Control | Not available |
| Braking transistor | External |
| Motor Thermal Protection | Not available |
Datasheet: PDF
