YASKAWA AC Drive J1000 | CIMR-JCBA0002BAA | 0.2/0.4 kW
- Rated output current: 1.6/1.9 A
- Max. applicable motor power: 0.2/0.4 kW
- Input power supply: 200 V
- Max Output Frequency: 400 Hz
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
YASKAWA AC Drive J1000 | CIMR-JCBA0002BAA | 0.2/0.4 kW
YASKAWA AC Drive
YASKAWA AC Drive Supplier in Bangladesh
J1000
Ultra Compact AC Drive
The J1000 meets all automation requirements for compact applications with variable speed operation and energy-saving characteristics. A wide range of useful functions upgrade your machine and offer great potentials.
- Stall Prevention Functions for stable operation during changes of load or power supply
- Over-Excitation Braking for quick deceleration without external braking resistor
- Detects load and automatically adjusts torque regardless the actual speed conditions
Technical Details
| Property | Value |
| Input power supply | 200 V |
| Rated output current (HD) | 1.6 A |
| Rated output current (ND) | 1.9 A |
| Overload Tolerance (ND) | 120 % for 60 s |
| Overload Tolerance (HD) | 150 % for 60 s |
| Max. applicable motor power (HD) | 0.2 kW |
| Max. applicable motor power (ND) | 0.4 kW |
| Input power phases | 1-phase |
| Motor type | Induction motor |
| Standards compliance | cUL, CE, RoHS, UL, UKCA |
| Ambient Temperature (Min) | -10 °C |
| Ambient Temperature (Max) | 40 °C |
| Ambient Temperature (Max) with Derating | 50 °C |
| Max. Humidity (non-condensing) | 95 % |
| Max. Altitude (without Derating) | 1000 m |
| Max. Altitude (with Derating) | 3000 m |
| Height | 128 mm |
| Width | 68 mm |
| Depth | 76 mm |
| Weight | 0.6 kg |
| Cooling method | Air cooling |
| Enclosure | IP20 (without top cover) |
| Environmental Specifications | Standard |
| Analog Input | 1 |
| Analog Output | 1 |
| Digital Input | 5 |
| Digital Output | 1 |
| Torque Control | Not available |
| Braking transistor | External |
| Motor Thermal Protection | Standard |
| Max Output Frequency | 400 Hz |
Datasheet: PDF
