YASKAWA CIPR-GA50CB001EBA

YASKAWA AC Drive GA500 | CIPR-GA50CB001EBA | 0.1/0.18 kW

  • Rated output current: 0.8/1.2 A
  • Max. applicable motor power: 0.1/0.18 kW
  • Input power supply: 200 V
  • Max Output Frequency: 590 Hz



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

YASKAWA AC Drive GA500 | CIPR-GA50CB001EBA | 0.1/0.18 kW

YASKAWA AC Drive

YASKAWA AC Drive Supplier in Bangladesh

GA500

The GA500 drive comes with valuable functions and smart features to provide benefits through the whole life cycle of a machine or installation. From drive selection, through design, installation, start-up or troubleshooting, the GA500 makes life easy.

  • One drive controlling any induction, permanent magnet or synchronous reluctance motor
  • Easy motor setup without the need for auto-tuning simplifies tuning with connected machinery
  • Convenient commissioning by programming without main power from PC or Smart Phone

Technical Details

Property Value
Input power supply 200 V
Rated output current (HD) 0.8 A
Rated output current (ND) 1.2 A
Overload Tolerance (ND) 110 % for 60 s
Overload Tolerance (HD) 150 % for 60 s
Max. applicable motor power (HD) 0.1 kW
Max. applicable motor power (ND) 0.18 kW
Input power phases 1-phase
EMC filter (embedded) ✓ Yes
Motor type Induction motor, Permanent magnet motor, Synchronous reluctance motor
Standards compliance cUL, CE, RoHS, UL, UKCA
Ambient Temperature (Min) -10 °C
Ambient Temperature (Max) 50 °C
Ambient Temperature (Max) with Derating 60 °C
Max. Humidity (non-condensing) 95 %
Max. Altitude (without Derating) 1000 m
Max. Altitude (with Derating) 4000 m
Height 128 mm
Width 68 mm
Depth 116 mm
Weight 0.7 kg
Cooling method Air cooling
Enclosure IP20
Environmental Specifications Standard
Analog Input 2
Analog Output 1
Digital Input 7
Digital Output 3
Safety Level SIL3
Performance Level PL e
Torque Control Standard
Braking transistor Built-in
Motor Thermal Protection Standard
Max Output Frequency 590 Hz



Datasheet: PDF
