DANFOSS Automation Drive FC 300 series 4.0 KW | 131B0001
- Power Rating: (P4K0) 4.0 KW / 5.0 HP
- Phase: Three phase
- Operating voltage: 380 – 500 VAC
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
DANFOSS Automation Drive FC-302P4K0T5E20H1XXXXXXSXXXXAXBXCXXXXDX | Part no: 131B0001
DANFOSS Automation Drive
DANFOSS Automation Drive Supplier in Bangladesh
DANFOSS Automation Drive AT A GLANCE
The VLT® Automation Drive represents a single drive concept that controls the entire range of operations from ordinary to servo like applications on any machine or production line.
Technical Details
| Gross weight | 5.346 Kilogram | ||
| Net weight | 4.5 Kilogram | ||
| Volume | 21.569 Liter | ||
| EAN | 5702427090569 |
| Product Group | FC- | VLT® AutomationDrive FC- | |
| Series | 302 | 302 | |
| Power Rating | P4K0 | (P4K0) 4.0 KW / 5.0 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 5 | 380 – 500 VAC | |
| Enclosure | E20 | (E20) IP20 / Chassis | |
| RFI Filter | H1 | (H1) RFI Class A1/B (C1) | |
| Brake – Safe Stop | X | No brake chopper | |
| LCP | X | No Loc. Cont. Panel | |
| Coating PCB | X | Not coated PCB | |
| Mains Option | X | No Mains Option | |
| Adaptation A | X | Standard Cable Entries | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Software Language Pack | X | Standard Language Pack | |
| A Option | AX | No A Option | |
| B Option | BX | No B Option | |
| C0 Option MCO | CX | No C0 option | |
| C1 Option | X | No C1 option | |
| C Option Software | XX | No software option | |
| D Option | DX | No D option | |
| Frame Size | A2 | A2 | |
| Modelcode01 | FC-302P4K0T5E20H1XXX | ||
| Modelcode02 | XXXSXXXXAXBXCXXXXDX | ||
| Product Catalog | NO_VIEW | NO VIEW | |
| Power 160% (HO) [KW] | 4 | 4 | |
| Power Loss HO [W] | 124 | 124 | |
| Power Loss HO [W] | 124 | 124 | |
| kVA | 6.93 | 6.93 | |
| Continuous Current (HO) [A] | 10 | 10 | |
| Intermittent Current (HO) [A] | 16 | 16 | |
| Continuous Current (HO) [A] | 8.2 | 8.2 | |
| Intermittent Current (HO) [A] | 13.1 | 13.1 | |
| Height [mm] | 268,0 | 268,0 | |
| Width w/ no C options [mm] | 90,0 | 90,0 | |
| Width w/ two C options [mm] | 150,0 | 150,0 | |
| Depth [mm] | 205,0 | 205,0 | |
| Depth with Option A/B [mm] | 220,0 | 220,0 | |
| Calculated Gross Weight [kg] | 5.346 | ||
| Calculated Net Weight [kg] | 4.5 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Product View (Switch) | GLBL | Global (Standard) |
Datasheet: PDF
