Description

Inductive sensors are the industrial standard for the contactless detection of metallic objects.
The Leuze product range includes a wide variety of standard and special sensors that are available in many different designs and have already been tried and tested millions of times by our customers.
In particular our extremely robust all stainless steel sensors, sensors with extended switching distance or miniature sensors for extremely constrained spaces have again and again proven to be ideal for challenging applications.

Basic sensors

The IS 100 series is the entry-level series into Leuze’s line of inductive switches. They are the economical solution for standard applications. In addition to the common cubic sensors, an extensive range of cylindrical sensors in short and long design as well as miniature sensors is available.

Standard sensors

The IS D series is the versatile standard for all sectors and industries. These sensors stand out for their extremely high reliability and durability. The portfolio prioritizes the most essential cylindrical designs M8, M12, M18 and M30. The unbeatable price-performance ratio makes IS D the first choice, especially for very large purchasing volumes.

Advanced sensors

Excellent technology and the highest quality standards form the basis of the IS 200 series, making them a reliable sensor in nearly all areas of application. The product range includes all common cubic and cylindrical standard and miniature designs and short and long designs. For designs M12 to M30 and 40×40, sensors are also available with complementary switching outputs (NO+NC) and 3x switching distance.

Special sensors

The IS 200 special sensors are characterized by an extra level of performance.
Extremely robust, all stainless steel sensors: Leuze’s all stainless steel sensors made of up to 1 mm thick V2A/V4A stainless steel are designed for use in environments with the highest requirements on the housing material. IP68/69K, pressure resistance and up to 3x switching distance are just a few of the technical features of this series. Furthermore, variants are available for the food and beverage sector with ECOLAB certification.
2-wire AC/DC sensors with large voltage range: These 2-wire sensors are very versatile thanks to their large voltage range of 10-320 V AC and V DC.

Inductive sensors with long operating range

New inductive sensors for switching distances up to 40 millimeters

Inductive sensors are used in all industries for the contactless detection of metals. The position detection of moving machine components is important for controlling the mechanics. Inductive sensors are the first choice, even if tools, input materials or end products made of steel, aluminum, copper alloys or stainless steel need to be detected.

Inductive sensors, also called proximity sensors, are known for reliably detecting metallic objects over short distances. Models with increased switching distances enable operating ranges up to three times longer than standard inductive sensors. The new sensors are therefore also suitable for applications with small installation spaces and/or large distances or tolerances – for example with inaccurate alignment, mechanical play or vibrations.

The new robust sensors with the designation IS 200MM.2 are made of nickel-plated brass and are available in cylindrical M12, M18 and M30 housings. They can even be used under high mechanical stress and provide highly accurate measurements and repeatability at a good price-performance ratio. The new sensors with switching distances of up to 40 millimeters can be installed quasi-flush or non-flush, depending on the respective application. The new sensors expand the existing inductive product portfolio.

Technical Features:-

Basic Data:-

Series	230
type. operating range limit S_n	15 mm
Operating range S_a	0 … 12.1 mm

Measurement Data:-

Repeatability

0.75 mm

Electrical Data:-

Protective circuit

Inductive protection
Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage U_B	10 … 320 V, AC/DC
Residual ripple	0 … 20 %, From U_B
Open-circuit current	0 … 1 mA
Temperature drift, max. (in % of S_r)	10 %, Over the entire operating temperature range
Repeatability, max. (in % of S_r)	5 %, For U_B = 20 … 30 V DC, ambient temperature T_a = 23 °C ± 5 °C
Switching hysteresis	20 %

Outputs:-

Number of digital switching outputs

1 Piece(s)

Switching Outputs:-

Voltage type	AC/DC
Switching current, max.	200 mA
Voltage drop	≤ 2 V

Switching Outputs 1:-

Switching element	Relay, NO
Switching principle	NO (normally open)

Time Behavior:-

Switching frequency	500 Hz
Oscillator frequency	50,000 Hz
Readiness delay	70 ms

Connection:-

Number of connections

1 Piece(s)

Connection 1:-

Function	Voltage supply
Type of connection	Cable
Cable length	2,000 mm
Sheathing material	PVC
Cable color	Black
Number of conductors	2 -wire
Wire cross section	0.34 mm²

Mechanical Data:-

Design	Cylindrical
Dimension (Ø x L)	30 mm x 50 mm
Thread size	M30 x 1.5 mm
Type of installation	Non-embedded
Housing material	Metal
Metal housing	Chromed brass
Sensing face material	Plastic, Polybutylene (PBT)
Net weight	180 g
Housing color	Red, RAL 3000 Silver
Type of fastening	Mounting thread Via optional mounting device
Standard measuring plate	45 x 45 mm², Fe360

Operation & Display:-

Type of display	LED
Number of LEDs	1 Piece(s)

Environmental Data:-

Ambient temperature, operation

-25 … 70 °C

Data Sheet: PDF
