KEYENCE LR-X100C

KEYENCE Photoelectric Sensors | LR-X100C

  • Sensing range (max.): 25.0 to 100.0 mm 0.98″ to 3.94″
  • Connection type: M8 connector type
  • Output Type: NPN
  • Light type: Green laser (505 nm)



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

KEYENCE Photoelectric Sensors | LR-X100C

KEYENCE Photoelectric Sensors

KEYENCE Photoelectric Sensors Supplier in Bangladesh

LR-X

Small Size, Stable Detection

The LR-X Series is a remarkably small laser sensor capable of detecting targets based on position and is unaffected by color, surface finish, or shape. Impressive durability is achieved with its food-grade stainles steel housing (SUS316L), high IP ratings, and guarded cable. Position changes as small as 0.5 mm (0.02 inch) are possible, along with automatic and real-time intensity adjustment to ensure stable detection on any target.



LR-X AT A GLANCE

Features
  • Unmatched stability in a remarkably small footprint
  • World’s first green laser cmos sensor
  • Detect targets regardless of appearance
  • Detailed OLED display, set up in minutes

Technical details-

Property Value
Model LR-X100C
Type M8 Connector Type*1
Detecting Distance 25.0 to 100.0 mm 0.98″ to 3.94″
Standard Detectable Deviation 1.0 mm 0.04″
Display Resolution 0.1 mm 0.004″
Spot Size Approx. 0.3 mm × 2 mm 0.012″ × 0.08″ (at a detecting distance of 100 mm 3.94″)
Response Time 500 µs*2/1 ms/3 ms/10 ms/200 ms Selectable
Light Source Type Green laser (505 nm)
Laser Class Class 1 Laser Product (IEC60825-1, FDA (CDRH), Part1040.10*3)
IO-Link Specification v1.1/COM2 (38.4 kbps)
Timer Function Timer OFF/Off-delay/On-delay/One-shot/On-Off delay/On-delay One-shot
Control Output
  1. NPN open collector/PNP open collector, N.O./N.C selectable. *4
  2. 30 VDC or lower, 50 mA or lower, Residual voltage 2 V or lower
External Input
  1. External Set/Laser OFF/Zero Shift/Hold Reset/Gyro Alert RST selectable *4
  2. Short circuit current – NPN: 1 mA or lower, PNP: 2 mA or lower
  3. Input time 3 ms or more ON, 20 ms or more OFF (25 ms or more ON, 25 ms or more OFF when External Set is selected only)
Protection Circuit Protection against reverse power connection, protection against output overcurrent, protection against output surge, protection against reverse output connection
Power voltage 16 to 30 VDC (including 10% ripple (P-P) or less), class 2
Power consumption
  1. During normal operation: 970 mW (38 mA or lower at 24 V, 53 mA or lower at 16 V) (Excluding Load Current)
  2. ECO ON/ALL: 821 mW (32 mA or lower at 24 V, 44 mA or lower at 16 V) (Excluding Load Current)
Enclosure rating IP65/IP67 (IEC60529)
Ambient light

Incandescent lamp: 16000 lux or less


Sunlight: 16000 lux or less
Ambient temperature -10°C to +50°C 14°F to + 122°F (no freezing)
Relative humidity 35 to 85% RH (no condensation)
Vibration resistance 10 to 500 Hz; Power Spectral Density: 0.816 G2/Hz for X, Y and Z axes
Shock resistance 1000 m/s2 (100G) 6 times each for X, Y, and Z axes
Material
  1. Head Case: SUS316L; Head Lens Cover: PSU
  2. Head Gasket: FKM (lens cover), EVM (cable)
  3. Cable: PVC
  4. Amplifier Case: PBT; Amplifier Display, Indicator: PAR; Amplifier Gasket: NBR; Button: POM
  5. Amplifier M8 Connector: SUS303
Accessories Instruction manual, laser warning label
Weight Approx. 35 g

*1 Ensure the cable length is 30 m 98.4′ or less for the M8 connector type. Ensure the cable length is 20 m 65.6′ or less when connecting via IO-Link.
*2 If 500 µs is selected, the following limitations apply.
· Only 2-point calibration can be performed.
· The detection range masking is set during calibration. (Manual setting of the masking range is not supported.)
· Output 2 is limited to an alarm output for errors and gyro issues, and standard/area cannot be used.
*3 Classification performed based on IEC60825-1 standards in accordance with FDA (CDRH) Laser Notice.
*4 The I/O can be selected from the following combinations. Control output × 2, Control output + External input

Datasheet: PDF
