SICK Photoelectric Sensors GL2S-P0311S24 | Part no: 1138542
- Functional principle: Photoelectric retro-reflective sensor
- Sensing range (max.): 0.02 m – 3 m
- Connection type: Cable with Tyco male connector, 3-pin, 1.26 m
- Output Type: PNP
- Switching frequency: 800 Hz
- Switching mode: Light switching
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Photoelectric Sensors GL2S-P0311S24 | Part no: 1138542
SICK Photoelectric Sensors
SICK Photoelectric Sensors Supplier in Bangladesh
G2
Cost-efficient miniature photoelectric sensor for use in tight installation spaces
Miniature photoelectric sensors of the G2 product family impress with their cost efficiency, small size and rugged sensor housing. The G2 is available in either slim or flat housing versions and can be easily integrated into small machines and very tight installation spaces. This means it offers a wide range of application possibilities. Thanks to the powerful background suppression, the sensors also offer reliable object detection. G2 photoelectric sensors can be installed quickly and easily, meaning they are very user-friendly.
G2 AT A GLANCE
- Space-saving integration in compact machines and very tight installation spaces
- Reliable detection status
- Versatile application possibilities
- Quick and easy mounting, commissioning and maintenance
- Cost-efficient solution
- Miniature housing: available either as G2 Slim or G2 Flat
- Powerful background suppression
- Rugged sensor housing
Technical details-
Features
| Functional principle | Photoelectric retro-reflective sensor |
| Functional principle detail | With minimum distance to reflector (dual lens system) |
| Dimensions (W x H x D) | 7.7 mm x 21.8 mm x 13.5 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 0.02 m … 3 m 1) |
| Sensing range | 0.03 m … 2.5 m 1) |
| Type of light | Visible red light |
| Light source | PinPoint LED 2) |
| Light spot size (distance) | Ø 11 mm (250 mm) |
| Wave length | 640 nm |
| Adjustment | None |
1) Reflector PL40A.
2) Average service life: 100,000 h at TU = +25 °C.
Mechanics/Electronics
| Supply voltage UB | 10 V DC … 30 V DC 1) |
| Ripple | < 5 Vpp 2) |
| Current consumption | 20 mA 3) |
| Switching output | PNP |
| Switching mode | Light switching |
| Output current Imax. | ≤ 50 mA |
| Response time | < 0.6 ms 4) |
| Switching frequency | 800 Hz 5) |
| Connection type | Cable with Tyco male connector, 3-pin, 1.26 m 6) |
| Cable material | Plastic, PVC |
| Cable diameter | Ø 3 mm |
| Circuit protection | A 7)
C 8) D 9) |
| Weight | 25 g |
| Polarisation filter | ✔ |
| Housing material | Plastic, ABS |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP67 |
| Ambient operating temperature | –30 °C … +50 °C |
| Ambient temperature, storage | –40 °C … +75 °C |
| UL File No. | NRKH.E181493 |
1) Limit values when operated in short-circuit protected network: max. 8 A.
2) May not fall below or exceed UV tolerances.
3) Without load.
4) Signal transit time with resistive load.
5) With light/dark ratio 1:1.
6) Do not bend below 0 °C.
7) A = VS connections reverse-polarity protected.
8) C = interference suppression.
9) D = outputs overcurrent and short-circuit protected.
Datasheet: PDF
