SICK Photoelectric Sensors VTB180-2F32417 | Part no: 6044020
- Functional principle: Photoelectric proximity sensor
- Sensing range (max.): 10 mm – 350 mm
- Connection type: Male connector M12, 4-pin
- Output Type: PNP
- Switching frequency: 500 Hz
- Switching mode: Light switching
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Photoelectric Sensors VTB180-2F32417 | Part no: 6044020
SICK Photoelectric Sensors
SICK Photoelectric Sensors Supplier in Bangladesh
V180
Lowest-cost cylindrical photoelectric sensor on the market!
The V180 sensors were developed to be able to offer a maximum scanning range. The cost-effective cylindrical sensors are easy to operate and simple to install and maintain. This minimizes the installation time and maintenance costs. The V180 sensors are available both in a plastic and metal housing. The bright red light LED with easily visible light spot simplifies installation. In addition, the highly visible status indicator makes troubleshooting quick and easy.
The V180 therefore provides an economical solution for many universal applications such as product detection, positioning in packaging machines, manufacturing automation, and material and conveying technology.
V180 AT A GLANCE
- Cost-effective cylindrical M18 sensor lowers installation costs
- Brightly lit red emitter LED simplifies alignment and saves mounting time
- Bright status display with 360° visibility enables quick and easy troubleshooting and thus reduces maintenance costs and time
- The flat, smooth front screen reduces the accumulation of dust and dirt. This ensures reliable operation and reduces both maintenance and costs
- Low-cost M18 housing sensor on the market
- Long sensing distances: 100 mm, 400 mm, 800 mm (proximity sensor), 300 mm (proximity sensor with BGS), 6 m (retro-reflective sensor) and 20 m (through-beam sensor)
- Bright power and signal LEDs with 360° visibility
- Wide product portfolio solves a broad range of applications
- High switching frequencies up to 1000 Hz
- Available in a metal housing for applications in harsh environments
- Optical axis selectively axial or radial (90°)
Technical details-
Features
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression |
| Dimensions (W x H x D) | 18 mm x 18 mm |
| Housing design (light emission) | Cylindrical |
| Thread diameter (housing) | M18 x 1 |
| Optical axis | Axial |
| Sensing range max. | 10 mm … 350 mm 1) |
| Sensing range | 30 mm … 200 mm 1) |
| Focus | Approx. 2.8° |
| Type of light | Visible red light |
| Light source | LED 2) |
| Light spot size (distance) | Ø 15 mm (300 mm) |
| Angle of dispersion | Approx. 2.8° |
| Wave length | 632 nm |
| Adjustment | Potentiometer, 4 turns (Sensing range) |
1) Object with 90% remission (based on standard white, DIN 5033).
2) Average service life: 100,000 h at TU = +25 °C.
Mechanics/Electronics
| Supply voltage UB | 10 V DC … 30 V DC 1) |
| Ripple | ± 10 % 2) |
| Current consumption | 35 mA 3) |
| Switching output | PNP |
| Switching mode | Light switching |
| Signal voltage PNP HIGH/LOW | Approx. VS – 1.8 V / 0 V |
| Output current Imax. | ≤ 100 mA |
| Response time | ≤ 1 ms 4) |
| Switching frequency | 500 Hz 5) |
| Connection type | Male connector M12, 4-pin |
| Circuit protection | A 6)
B 7) D 8) |
| Protection class | III |
| Weight | 18 g |
| Housing material | Plastic, PBT/PC |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP67 |
| Items supplied | Fastening nuts (2 x) |
| Ambient operating temperature | –25 °C … +55 °C |
| Ambient temperature, storage | –40 °C … +70 °C |
1) Limit values when operated in short-circuit protected network: max. 8 A.
2) May not fall below or exceed UV tolerances.
3) Without load.
4) Signal transit time with resistive load.
5) With light/dark ratio 1:1.
6) A = VS connections reverse-polarity protected.
7) B = inputs and output reverse-polarity protected.
8) D = outputs overcurrent and short-circuit protected.
Datasheet: PDF
