Pepperl+Fuchs ML29-P_25_103_115

Pepperl+Fuchs Photoelectric Sensors | ML29-P/25/103/115

  • Functional principle: Thru-beam sensor
  • Effective detection range: 0 m – 6 m
  • Connection type: 6 m fixed cable
  • Switching type: Light-on
  • Switching frequency: 100 Hz
  • Light type: Modulated infrared light



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

Pepperl+Fuchs Photoelectric Sensors | ML29-P/25/103/115

Pepperl+Fuchs Photoelectric Sensors

Pepperl+Fuchs Photoelectric Sensors Supplier in Bangladesh

Photoelectric Sensors

Pepperl+Fuchs offers an extensive portfolio of standard photoelectric sensors and measurement technology precisely engineered for the demands of industrial automation. Various sensing modes, including conventional thru-beam sensors and diffuse mode sensors to high-performance distance sensors, are available in miniature, standard, and specialized designs. This forward-thinking portfolio concept guarantees maximum flexibility for users.

Aside from machine and plant construction and the automotive industry, photoelectric sensors are primarily used in material handling, mobile equipment, and the packaging and electronics industries.



ML29-P/25/103/115 AT A GLANCE
Benefits
  • Single-beam monitoring with extremely narrow sensor
  • Integrated circuit
  • Test
  • Simple installation – Plug & Play
  • Ideal for installation in door profiles or frames
  • Light on version

Technical details-

General specifications

Effective detection range 0 … 6 m
Threshold detection range 8.5 m
Light source IRED
Light type modulated infrared light
Opening angle +/- 8 °
Optical face lateral
Ambient light limit 40000 Lux



Mechanical specifications

Degree of protection IP65
Connection 6 m fixed cable
Material
Housing PMMA , black
Optical face Plastic pane
Mass per device 12 g
Dimensions
Height 85.2 mm
Width 11.6 mm
Depth 9.2 mm



Datasheet: PDF
