KEYENCE Inductive Proximity Sensors | EV-130F
- Sensing range (max.): 10 mm 0.39″ ±10%
- Output function: NO
- Switching frequency: 250 Hz
- Installation type: Shielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
KEYENCE Inductive Proximity Sensors | EV-130F
KEYENCE Inductive Proximity Sensors
KEYENCE Inductive Proximity Sensors Supplier in Bangladesh
EV-F
Spatter-resistant,two-wire proximity sensors
Spatter-resistant Proximity Sensor
Technical details-
| Property | Value |
| Model | EV-130F |
| Type | Spatter-resistant/Shielded |
| Shape | M30 |
| Detecting distance | 10 mm 0.39″ ±10% |
| Detectable object | Ferrous metals (see Characteristics for nonferrous metals) |
| Standard target (iron, t=1 mm 0.04″) | 30 x 30 mm 1.18″ x 1.18″ |
| Hysteresis | 15% max. of detecting distance |
| Response frequency | 250 Hz |
| Operation mode | N.O. |
| Temperature characteristics | ±10% max. of detecting distance at 23°C 73.4°F, within -25 to +70°C -13 to +158°F |
| Control output (switching capacity) | 5 to 200 mA |
| Protection circuit | Reversed polarity, short-circuit, surge voltage |
| Cable length | 2 m 6.6′ |
| Power voltage | 12 to 24 VDC, Ripple (P-P) 20 % or less |
| Current consumption (leakage current) | 1.0 mA max., Residual voltage: 3.6 V max. (with 2-m 6.6′ cable) |
| Residual voltage | 3.6 V max. (with 2-m 6.6′ cable) |
| Enclosure rating | IP67 |
| Ambient temperature | -25 to +80 °C -13 to 176 °F (No freezing) |
| Relative humidity | 35 to 95 % RH (No condensation) |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 500 m/s2, 3 times in each of the X, Y, and Z directions |
| Case material | Fluoro-chemical-coated brass |
| Accessories | Screw nut x 2, toothed washer x 1 |
| Weight | Approx. 300 g |
Datasheet: PDF
More Inductive proximity sensors :
KEYENCE EV-112F, KEYENCE EV-118F, KEYENCE EV-112FSO(2073), KEYENCE EV-118FSO(2074)
