KEYENCE Inductive Proximity Sensors | EZ-18T
- Sensing range (max.): 5 mm 0.20″ ±10%
- Switching output: NPN
- Output function: NO/NC
- Switching frequency: 350 Hz
- Installation type: Shielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
KEYENCE Inductive Proximity Sensors | EZ-18T
KEYENCE Inductive Proximity Sensors
KEYENCE Inductive Proximity Sensors Supplier in Bangladesh
EZ
Three-wire self contained amplifier proximity sensors
Shorter, space saving sensor bodies with high detection sensitivity and long detection distances.
Technical details-
| Property | Value |
| Model | EZ-18T |
| Type | Shielded |
| Shape | M18 |
| Detecting distance | 5 mm 0.20″ ±10% |
| Detectable object | Ferrous metals (see Characteristics for nonferrous metals) |
| Standard target (iron, t=1mm 0.04″) | 18 x 18 mm 0.71″ x 0.71″ |
| Hysteresis | 10% max. of detecting distance |
| Response frequency | 350 Hz |
| Operation mode | N.O./N.C. |
| Temperature characteristics | ±10% max. of detecting distance at +23°C 73.4°F, within -25 to +70°C -13 to 158°F |
| Control output | NPN open collector 100 mA max. (40 V max.), Residual voltage: 1 V max. |
| Cable length | 2 m 6.6′ |
| Power voltage | 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less |
| Current consumption | 13 mA or less |
| Enclosure rating | IP67 |
| Ambient temperature | -25 to +80 °C -13 to 176 °F (No freezing) |
| Relative humidity | 35 to 95 % RH (No condensation) |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 1,000 m/s2, 3 times in each of the X, Y, and Z directions |
| Case material | Nickel-plated brass |
| Accessories | Screw nut x 2, toothed washer x 1 |
| Weight | Approx. 130 g |
Datasheet: PDF
More Inductive proximity sensors :
KEYENCE EZ-8M, KEYENCE EZ-12M, KEYENCE EZ-18M, KEYENCE EZ-30M
