KEYENCE PX-10C

KEYENCE Photoelectric Sensors | PX-10C

  • Power voltage: 12 to 24 VDC
  • Connection type: Connector
  • Output Type: NPN
  • Weight: Approx. 50 g



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

KEYENCE Photoelectric Sensors | PX-10C

KEYENCE Photoelectric Sensors

KEYENCE Photoelectric Sensors Supplier in Bangladesh

PX

Heavy-duty Photoelectric Sensors

The PX Series has high power and is highly robust. It features stainless steel sensing heads that are water and oil resistant along with an amplifier that provides dual outputs. It has a range of up to 40m (131.2′) and offers hard wired and M12 connector cable options.



PX AT A GLANCE

Features
  • Water-resistant and Oil-resistant IP68G/IP69K Structure
  • Impressive Thrubeam Strength
  • Washdown Resistant Amplifier

Technical details-

Property Value
Model PX-10C
Type Connector type
Output NPN
Response time 500 µs (TURBO) / 1 ms (SUPER) / 4 ms (ULTRA) / 16 ms (MEGA)
Output selection LIGHT-ON/DARK-ON
Indicator lamp
• Operation indicator: Red LED x 2, DSC orange LED x 1


• Dual digital monitor: Dual 7-segment display [Preset value (4-digit green LED) and current value (4-digit red LED) illuminated together, current value range: 0 to 65504, excess gain: 0 P to 999 P]


• Hold function: Possible to display both peak and bottom hold values. Selectable from 5 variations.


• Bar LED monitor [Excess gain displayed (85% to 115% in 7 steps)]


• Scaling display
Detection mode Light intensity (automatic sensitivity-tracking function provided) / [Limit light intensity/output monitor]
Shift function Variable between –1999 and 9999
Timer function
Timer OFF/OFF-delay/ON-delay/One-shot/ON-delay, OFF-delay/ON-delay, One-shot


Timer duration selectable: 1 ms to 9999 ms


Maximum error against the setting value: 10% max.
Control output NPN open-collector 40 V, 100 mA max. for an output/100 mA max. for two outputs, residual voltage 1 V max.
External input ―
Interference prevention Up to 4 units (in all power modes)*1
Power voltage 12 to 24 VDC, Ripple (P-P) 10 % or less, Class2*2
Power consumption
Standard mode: 50 mA max. at 24 V/55 mA max. at 12 V


Power saving mode: 40 mA max. at 24 V/45 mA max. at 12 V
Enclosure rating IEC: IP67/JEM: IP67/NEMA: 4X
Ambient temperature -10 to +55 °C 14 to 131 °F (No freezing)*3
Relative humidity 35 to 85 % RH (No condensation)
Vibration resistance 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions
Case material Housing: PBT, display: PSU, display cover/connector cover: SUS304, radiator plate: SUS304, gasket: NBR
Weight Approx. 50 g

*1 The received light intensity may vary somewhat when the sensor head’s cable layout is changed, so redo the sensitivity setting when changing the layout. The interference prevention function is affected
somewhat when using multiple units installed adjacent to each other. Fine-tune the sensitivity (increase the setting) for adjacent layouts.
*2 Use a 24 VDC power voltage when using a head light transmitting cable of 3 m 9.8′ or more (PX-H71/H71TZ) or 10 m 32.8′ or more (PX-H72).
*3 When using multiple units connected adjacently, the ambient temperature varies with the conditions below.
2 to 4 Units: -10 to +50 °C 14 to 122 °F, 5 to 17 Units: -10 to +45 °C 14 to 133 °F.

Datasheet: PDF
