SICK WLD4FP-228121A0ZZZ

SICK Photoelectric Sensors WLD4FP-228121A0ZZZ | Part no: 1129442

  • Functional principle: Photoelectric retro-reflective sensor
  • Sensing range: 0.015 m – 4.5 m
  • Connection type: Male connector M8, 4-pin
  • Output Type: PNP
  • Switching frequency: 1000 Hz
  • Switching mode: Light/dark switching



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SICK Photoelectric Sensors WLD4FP-228121A0ZZZ | Part no: 1129442

SICK Photoelectric Sensors

SICK Photoelectric Sensors Supplier in Bangladesh

W4

Powerful miniature photoelectric sensors and photoelectric proximity sensors for automation

W4 miniature photoelectric sensors and photoelectric proximity sensors are the ideal solution for the intelligent automation of industrial processes. The powerful sensors in the miniature housing reliably detect glossy, flat, uneven, perforated and transparent objects and detect a wide range of parameters such as remission and distance values. Due to the selection of different designs, housing materials and light sources, the sensors are well-suited to countless applications and nearly any assembly situation. The profile is rounded out with an intuitive operating concept and intelligent diagnostic functions.



W4 AT A GLANCE

Benefits
  • Fault-free system operation thanks to reliable and rugged object detection with Optical Experts
  • The all-in-one photoelectric proximity sensor, WTM4FF (housing: flat), WTM4SF (housing: slim), for a variety of applications reduces the effort for storage and handling, saves costs and simplifies processes
  • Solution for demanding detection tasks thanks to different light sources
  • Intuitive and quick commissioning, alignment and adjustment
  • Protection from disruptive environmental influences
Features
  • DoubleLine, ClearSens, V-Optik, Spot Size Recognition
  • Two independent switching points, fast distance value output, DustAlert
  • Powerful, well-visible LEDs: PinPoint-Pro, PinPoint; Infrared; Laser: red light
  • Optical alignment aid, Teach-Turn adjustment, IO-Link
  • Housing: VISTAL or stainless steel, –40 °C … +60 °C

Technical details-

Features

Functional principle Photoelectric retro-reflective sensor
Functional principle detail With minimum distance to reflector (dual lens system)
Sensing range
Sensing range min. 0 m
Sensing range max. 4.5 m
Maximum distance range from reflector to sensor (operating reserve 1) 0.015 m … 4.5 m
Recommended distance range from reflector to sensor (operating reserve 3,75) 0.035 m … 3.9 m
Reference reflector Reflector P250
Recommended sensing range for the best performance 0.035 m … 3.9 m
Polarisation filter Yes
Emitted beam
Light source PinPoint LED
Type of light Visible red light
Shape of light spot Point-shaped
Light spot size (distance) Ø 38 mm (1,000 mm)
Maximum dispersion of the emitted beam around the standardized transmission axis (squint angle) < +/- 1.5° (at TU = +23 °C)
Key LED figures
Normative reference EN 62471:2008-09 | IEC 62471:2006, modified
LED risk group marking Free group
Wave length 635 nm
Average service life 100,000 h at Ta = +25 °C
Adjustment
None –
Display
LED green Operating indicator
Static on: power on
LED yellow Status of received light beam
Static on: object not present
Static off: object present
Flashing: Below the 1.5 function reserve



Electronics

Supply voltage UB 10 V DC … 30 V DC 1)
Ripple ≤ 5 Vpp
Usage category DC-12 (According to EN 60947-5-2)

DC-13 (According to EN 60947-5-2)
Current consumption ≤ 20 mA, without load. At UB = 24 V
Protection class III
Digital output
Number 2 (Complementary)
Type PNP
Switching mode Light/dark switching
Signal voltage PNP HIGH/LOW Approx. UB-2.5 V / 0 V
Output current Imax. ≤ 100 mA
Circuit protection outputs Reverse polarity protected
Overcurrent protected
Short-circuit protected
Response time ≤ 500 µs
Repeatability (response time) 150 µs 2)
Switching frequency 1,000 Hz 3)
Pin/Wire assignment
Function of pin 4/black (BK) Digital output, light switching, object present → output Q LOW
Function of pin 2/white (WH) Digital output, dark switching, object present → output ǬL1 HIGH

1) Limit values.

2) Signal transit time with resistive load in switching mode.

3) With light/dark ratio 1:1.

Datasheet: PDF
