KEYENCE Photoelectric Sensors | PZ-M61
- Functional principle: Polarized retro-reflective
- Sensing range (max.): 0.1 to 1.5 m
- Output Type: NPN
- Light type: Red LED
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
KEYENCE Photoelectric Sensors | PZ-M61
KEYENCE Photoelectric Sensors
KEYENCE Photoelectric Sensors Supplier in Bangladesh
PZ-V/M
Built-in amplifier photoelectric sensors
The PZ-V/M Series automatically increases power when dirty, is in a durable resin housing, has background suppression, and is unaffected by color or angle. It has a range of up to 10m (32.8′) and offers hard wired, M8 connector, and M12 connector cable options.
PZ-V/M AT A GLANCE
- Detections are unaffected by variations in target color or angle
- Excellent resistance to dust and dirt
- One touch, fully automatic calibration
- Unaffected by highly reflective target backgrounds
- 40 model variations available including quick disconnect types
- High-power red LED(Except for PZ-M71/V71)
Technical details-
| Property | Value |
| Model | PZ-M61 |
| Type | Polarized retro-reflective |
| Output | NPN |
| Detecting distance | 0.1 to 1.5 m 0.3′ to 4.9′ (When R-5 reflector is used)*1 |
| Setting distance | ― |
| Light source | Red LED |
| Sensitivity adjustment | 1-turn trimmer (230°) |
| Response time | 1.5 ms max. |
| Operation mode | LIGHT-ON/DARK-ON (switch-selectable) |
| Indicator lamp | Output: orange LED, stable operation: green LED |
| Control output | 100 mA (24 V) max., Residual voltage: 1 V max. |
| Digital monitor | ― |
| Protection circuit | Reversed polarity, overcurrent protection, surge absorber |
| Power voltage | 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less |
| Power consumption | 34 mA max. |
| Enclosure rating | IP67 |
| Ambient light | Incandescent lamp: 5,000 lux max., Sunlight: 20,000 lux max. |
| Ambient temperature | -20 to +55 °C -4 to 131 °F (No freezing) |
| Relative humidity | 35 to 85 % RH (No condensation) |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 1,000 m/s2, 6 times in each of the X, Y, and Z directions |
| Case material | Glass-fiber reinforced plastic |
| Accessories | Reflector R-5 |
| Weight | Approx. 55 g (including 2-m 6.6′ cable) |
*1 The detecting distance is obtained with the maximum sensitivity.
*2 The transmitter of the PZ-M51 features a power indicator only.
Datasheet: PDF
