DATALOGIC_DATASENSING AES_AP-3A8R

DATALOGIC/DATASENSING Inductive Proximity Sensors | AES/AP-3A8R

  • Sensing range (max.): 2 mm
  • Connection type: 10m PVC Cable
  • Switching output: PNP
  • Output function: NO
  • Switching frequency: 7 kHz
  • Installation type: Shielded



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

DATALOGIC/DATASENSING Inductive Proximity Sensors | AES/AP-3A8R

DATALOGIC/DATASENSING Inductive Proximity Sensors

DATALOGIC/DATASENSING Inductive Proximity Sensors supplier in Bangladesh

AES

Miniaturized inductive sensors with M8 diameter. Where small spaces required small dimensions.

  • Miniaturized dimensions: M8 x 20 mm (cable) / 30 mm (plug) lenght
  • Shielded models with sensing distance: 1.5 mm / 2 mm
  • Output current: 100 mA
  • ASIC inside: high reliability and repeatibility
  • Totally protected against electrical damages
  • Cable and plug M8 output
  • Stainless steel AISI303 housing

Technical details-

Detection properties
Nominal sensing distance 2mm
Operanting distance 0…1,62mm
Standard target 8x8mm FE360
Correction Factor copper: 0,15 ± 10% / aluminium: 0,15 ± 10% / brass: 0,21 ± 10% / stainless steel: 0,56 ± 10%
Thermal drift of Sr < 10%
Repeat Accuracy < 5% (UB 24V Ta=23°C ±5°C)
Hysteresis 1 … 20%
Application
Description M8 mini flush mount
Functions Proximity
Outputs
Output type PNP
Output Function NO
Switching frequency 7kHz
Electrical data
Operating Voltage 10…30Vdc
No-Load supply current ≤ 10mA
Load current ≤ 100mA
Leakage current ≤ 10μA
Output voltage drop ≤ 1,5V @100mA
Max ripple content ≤ 10%
LED indicators Yellow LED output state
Time delay before availability ≤ 50ms
Short-circuit protection Yes
Reverse Polarity Protection Yes
Impulsive Overvoltage Protection Yes
Protection against inductive loads Yes
Mechanical data
Mounting Shielded
Material AISI303 Stainless Steel
Housing material AISI 303 Stainless Steel
Connections 10m PVC Cable
Active Head Material PBT
Tightening torque 5Nm
Diameter/Dimension M8



Datasheet: PDF
