DATALOGIC/DATASENSING Capacitive Proximity Sensors | C12P/00-3E
- Sensing range (max.): 0.5 – 4mm shielded; 0.5 – 8mm unshielded
- Connection type: M12 plug
- Switching output: NPN/PNP
- Output function: NO/NC
- Switching frequency: ≤15Hz
- Installation type: Shielded/Unshielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
DATALOGIC/DATASENSING Capacitive Proximity Sensors | C12P/00-3E
DATALOGIC/DATASENSING Capacitive Proximity Sensors
DATALOGIC/DATASENSING Capacitive Proximity Sensors supplier in Bangladesh
C12
Very compact solution detecting any kind of material.
- DC supply voltage
- High noise immunity
- Shielded and unshielded models
- Adjustable sensitivity by Teach-In button
- Plastic housing
Technical details-
| Nominal sensing distance | 0,5…4mm shielded; 0,5…8mm unshielded |
| Thermal drift of Sr | < 20% |
| Repeat Accuracy | 5% |
| Sensitivity adjustment | Yes |
| Hysteresis | ≤ 20% |
| Output type | NPN/PNP |
| Output Function | NO/NC |
| Switching frequency | ≤15Hz |
| Operating Voltage | 10…40Vdc |
| No-Load supply current | ≤ 12mA |
| Load current | ≤ 200mA |
| Leakage current | ≤ 300μA |
| Output voltage drop | ≤ 2,5V @ IL = 200mA |
| Max ripple content | ≤10% |
| LED indicators | Yellow LED (object detected), green LED power supply/stability |
| Time delay before availability | ≤ 200ms |
| Short-circuit protection | polarity reversal, overvoltage |
| Reverse Polarity Protection | Yes |
| Impulsive Overvoltage Protection | Yes |
| Dimensions | M12 x 1 / L = 80mm |
| Mounting | Shielded/Unshielded |
| Housing material | Polyester |
| Weight | 30g |
| Connections | M12 plug |
| Active Head Material | Polyester |
| Operating temperature | -35°C…+85°C (without freeze) |
| Storage temperature | -40°C…+85°C |
| Diameter/Dimension | M12 |
Datasheet: PDF
