SICK Capacitive Proximity Sensors CM12-08EBP-KC1 | Part no: 6051030
- Sensing range (max.): 0.5 mm – 8 mm (For non-flush installation), 0.5 mm – 4 mm (For flush mounting
- Connection type: Male connector M12, 4-pin
- Switching output: PNP / NPN
- Output function: NC or NO
- Switching frequency: 15 Hz
- Installation type: Non-flush / flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Capacitive Proximity Sensors CM12-08EBP-KC1 | Part no: 6051030
SICK Capacitive Proximity Sensors
SICK Capacitive Proximity Sensors Supplier in Bangladesh
CM
Rugged and cost-effective capacitive sensors
The CM capacitive proximity sensors detect objects and levels regardless of color, reflectance, and gloss of the surfaces. In the process, they detect powdery, granulated, liquid, and solid materials – even through non-metallic walls made of plastic or glass. The proven and rugged sensors are cost-effective and feature high electromagnetic compatibility (EMC), which prevents switching errors and reduces downtime. The variants with a PTFE housing are ideal for detecting the levels of chemical compounds, e.g. acids or solvents.
- Cost-effective sensors for traditional maximum fill level detection and object detection
- Less machine downtimes thanks to high shock and vibration resistance
- Stable processes thanks to high EMC and easy switching point adjustment using a potentiometer or teach-in button
- Quick installation thanks to visual adjustment indicator and universal mounting systems
- Especially durable PTFE variants for use in aggressive ambient conditions
- Cylindrical housing in M12, M18, and M30 models
- Sensing ranges of up to 25 mm
- Enclosure rating: IP67, IP68, IP69K
- Visual adjustment indicator
- High electromagnetic compatibility
- Electrical configuration: DC 4-wire and AC 2-wire
- Adjustment of the switching point via potentiometer (M18 and M30) and teach-in button (M12)
Technical details-
Features
| Housing | Metric | ||||||
| Thread size | M12 x 1 | ||||||
| Diameter | Ø 12 mm | ||||||
| Sensing range Sn | 0.5 mm … 8 mm 1)
0.5 mm … 4 mm 2) |
||||||
| Safe sensing range Sa | 5.76 mm | ||||||
| Installation type | Non-flush / flush 3) | ||||||
| Switching frequency | 15 Hz | ||||||
| Connection type | Male connector M12, 4-pin | ||||||
| Switching output | PNP / NPN | ||||||
| Switching output detail | PNP / NPN | ||||||
| Output function | NC or NO | ||||||
| Output characteristic | Wire configurable 4) | ||||||
| Electrical wiring | DC 4-wire | ||||||
|
|||||||
| Enclosure rating | IP68 (According to EN 60529) 5) | ||||||
| Items supplied | Mounting nut, PA12 plastic (2x) | ||||||
1) For non-flush installation.
2) For flush mounting.
3) For flush mounting, Teach-in necessary.
4) Automatic detection.
5) 1.3 m water depth / 60 min.
Mechanics & Electronics
| Supply voltage | 10 V DC … 36 V DC |
| Ripple | ≤ 10 % 1) |
| Voltage drop | ≤ 2.5 V DC 2) |
| Current consumption | 12 mA 3) |
| Time delay before availability | ≤ 120 ms |
| Hysteresis | 3 % … 20 % |
| Reproducibility | ≤ 5 % 4)
5) |
| EMC | According to EN 60947-5-2 6) |
| Continuous current Ia | ≤ 200 mA |
| Short-circuit protection | ✔ |
| Power-up pulse protection | ✔ |
| Shock and vibration resistance | 30 g, 11 ms / 10 … 55 Hz, 1 mm |
| Ambient operating temperature | –20 °C … +85 °C |
| Ambient temperature, storage | –40 °C … +85 °C |
| Housing material | Plastic |
| Housing length | 84.7 mm |
| Thread length | 46.5 mm |
| Tightening torque, max. | ≤ 1 Nm |
| UL File No. | NRKH.E191603 |
1) Of Ub.
2) At Ia max.
3) Without load.
4) Of Sr.
5) Supply voltage UB and constant ambient temperature Ta.
6) For non-flush installation min. 1 x Sn and sensor grounded.
Datasheet: PDF
