SICK Capacitive Proximity Sensors CMB30-25NPPEC0SA00 | Part no: 6080644
- Sensing range (max.): 0 mm – 25 mm
- Connection type: Male connector M12, 4-pin
- Switching output: PNP
- Output function: Complementary
- Switching frequency: 50 Hz
- Installation type: Non-flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Capacitive Proximity Sensors CMB30-25NPPEC0SA00 | Part no: 6080644
SICK Capacitive Proximity Sensors
SICK Capacitive Proximity Sensors Supplier in Bangladesh
CMB
Smart and rugged capacitive sensors
The CMB capacitive proximity sensors detect objects and levels regardless of color, reflectance and gloss of the surfaces. In the process, they detect powdery, granulated, liquid and solid materials – even through non-metallic walls made of plastic or glass, for example. The proven and rugged sensors are cost efficient and feature extremely high electromagnetic compatibility (EMC), which prevents switching errors and reduces downtime. Thanks to the IO-Link interface, different parameterizations can be performed and detailed data read out. This makes the CMB devices suitable for more complex applications and enables predictive maintenance.
- Cost-effective sensors for classic and more complex applications
- Less machine downtime thanks to high shock and vibration resistance and numerous diagnostic options
- Stable processes thanks to very good EMC and precise switching point settings
- Quick installation thanks to visual adjustment indicator and universal mounting systems
- Optimization of stock thanks to diverse application options and various setting options via IO-Link
- Smart Sensors make machine processes quicker, more efficient and transparent and enable predictive maintenance as well as Industry 4.0 applications
- Cylindrical housing in M18 and M30 models
- Sensing ranges of up to 25 mm
- Enclosure rating: IP67, IP68, IP69K
- Temperature: −30 °C to +85 °C
- Visual adjustment indicator
- Available Smart Sensor: Enhanced Sensing, IO-Link, Diagnostics, Smart Tasks
- Adjustment of the switching point via potentiometer, cable or IO-Link
- Ecolab certified
Technical details-
Features
| Housing | Metric | ||||||||
| Thread size | M30 x 1.5 | ||||||||
| Diameter | Ø 30 mm | ||||||||
| Sensing range Sn | 0 mm … 25 mm | ||||||||
| Safe sensing range Sa | 19.13 mm 1) | ||||||||
| Installation type | Non-flush | ||||||||
| Switching frequency | 50 Hz | ||||||||
| Connection type | Male connector M12, 4-pin | ||||||||
| Switching output | PNP | ||||||||
| Switching output detail | PNP | ||||||||
| Output function | Complementary | ||||||||
| Output characteristic | Wire configurable | ||||||||
| Electrical wiring | DC 4-wire | ||||||||
|
|||||||||
| Enclosure rating | IP67
IP68 2) IP69K |
||||||||
| Special features | Visual adjustment indicator | ||||||||
| Pin 2 configuration | External input, Teach-in, switching signal | ||||||||
| Items supplied | Mounting nut, PA12 plastic (2x)
Screwdriver for potentiometer adjustment (1 x) |
||||||||
1) For flush mounting in electrically conductive materials Sa = 0.8 x Sr at temperatures <0 °C and >60 °C.
2) 1 m water depth / 60 min.
Mechanics & Electronics
| Supply voltage | 10 V DC … 36 V DC |
| Ripple | ≤ 10 % 1) |
| Voltage drop | ≤ 2 V DC 2) |
| Current consumption | ≤ 20 mA 3) |
| Time delay before availability | ≤ 300 ms |
| Hysteresis | 3 % … 20 % |
| Reproducibility | ≤ 5 % 4)
5) |
| Temperature drift (of Sr) | ± 10 % |
| EMC | EN 61000-4-2 ESD: > 40 kV CD and AD
EN 61000-4-3 Radiated RF: 20 V/m EN 61000-4-4 burst: +/- 4 kV / 5 kHz EN 61000-4-5 Surge: Voltage supply > 2 kV with 500 ohm; switching output > 2 kV with 500 ohm EN 61000-4-6 HF: > 20 Vrms EN 61000-4-8 mains frequency magnetic fields: Permanent > 60 A/m, 75,9 µ tesla; briefly > 600 A/m, 759 µ tesla |
| Continuous current Ia | ≤ 200 mA |
| Short-circuit protection | ✔ |
| Power-up pulse protection | ✔ |
| Shock and vibration resistance | EN 60068-2-27 shock resistance Ea: 30 g 11 ms; 3 shocks in each direction of the 3 coordinate axes
IEC 60068-2-31 drop test: 2 times from 1 m, 100 times from 0.5 m EN 60068-2-6 vibration resistance Fc: 10 Hz … 150 Hz, 1 mm / 15 g |
| Ambient operating temperature | –30 °C … +85 °C 6) |
| Ambient temperature, storage | –40 °C … +85 °C |
| Housing material | Plastic, PBT |
| Housing length | 74 mm |
| Thread length | 45.5 mm |
| Tightening torque, max. | ≤ 7.5 Nm |
| UL File No. | NRKH.E191603 |
1) Of Ub.
2) At Ia max.
3) Without load.
4) Of Sr.
5) Supply voltage UB and constant ambient temperature Ta.
6) +120 °C short time, at the front of the sensor.
Datasheet: PDF
More Capacitive proximity sensors :
SICK CMB30-25NPPEW2SA00 (6080643), SICK CMB30-16BPPEC0SA00 (6080642), SICK CMB18-08BPPEC0SA00 (6080638), SICK CMB18-08BPPEW2SA00 (6080637), SICK CMB30-16BPPEW2SA00 (6080641), SICK CMB18-12NPPEW2SA00 (6080639), SICK CMB18-12NPPEC0SA00 (6080640)
