ALTHEN AMS-3946 Displacement Sensor

ALTHEN Displacement Sensor

Compact and robust displacement sensor for reliable magnetic material detection in harsh industrial environments.

ALTHEN SENSOR SUPPLIER IN BANGLADESH

Performance highlights

The AMS 3946 is a high-performance displacement sensor designed for detecting magnetic materials with precision and reliability. It features a compact signal conditioning module, offering a wide gain and offset adjustment range, and high-speed response with a bandwidth of 5 kHz.

Usage conditions

Designed for demanding environments, the AMS 3946 operates reliably between -20°C and +80°C. The stainless steel housing ensures IP67 protection, and an optional hermetic all-welded version is available for extreme durability. Pressure capabilities range from 500 psi up to an optional 22,500 psi.

Possible applications:

• Magnetic target position detection
• Machine condition monitoring
• Runout or shaft displacement measurement
• Hydraulic cylinder position feedback
• Precision machinery diagnostics

Advantages of choosing this product

Thanks to its robust design and versatile signal output (0-10 VDC standard, 0–5 VDC or ±5 VDC optional), the AMS 3946 is suited for both OEM and retrofit solutions. The modular system—with a removable cable and compact DIN rail electronics—allows easy integration and servicing.

Other important features:

• Removable cable options
• Signal electronics with DIN rail mounting
• Wide input voltage: +12 to 28 VDC
• Low power consumption (0.56 W max)
• Storage temperature: -50°C to +150°C
