TURCK UC15-S18-IOL-H1141

TURCK Capacitive Proximity Sensors UC15-S18-IOL-H1141 | Part no: 100050169

  • Sensing range (max.): 5 mm
  • Connection type: Connector, M12 × 1
  • Switching output: PNP/NPN
  • Output function: NO/NC programmable



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

TURCK Capacitive Proximity Sensors UC15-S18-IOL-H1141 | Part no: 100050169

TURCK Capacitive Proximity Sensors

TURCK Capacitive Proximity Sensors supplier in Bangladesh

Capacitive Sensors

Capacitive sensors utilize a non-contact sensing technology that detects a wide variety of materials. These sensors make use of a compensation electrode, and most come with sensitivity adjustments that allow a designer to tune out certain materials such as glass or plastic, making this type of sensor a common choice for point level applications

Features
  • M18 × 1 threaded barrel
  • Plastic, PA12‐GF30
  • Digital potentiometer
  • Three different teach functions
  • Can be parameterized via IOL
  • Two switching outputs, can be parameterized independently
  • Highly visible LED

Technical data

Design Threaded barrel
Construction size M18 x 1
Rated switching distance 5 mm
Operating voltage 10…30 VDC
Output function NO/NC programmable, PNP/NPN
Communication protocol IO-Link
Electrical connection Connector, M12 × 1
Housing material PA12-GF30
Ambient temperature -40…+60 °C
Protection class IP67



Datasheet: PDF
