OMRON Capacitive Proximity Sensors | E2K-L26MC1 2M
- Connection type: 2 m, Pre-wired models
- Switching output: NPN open collector
- Output function: NO
- Switching frequency: 100 Hz
- Installation type: Unshielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
OMRON Capacitive Proximity Sensors | E2K-L26MC1 2M
OMRON Capacitive Proximity Sensors
OMRON Capacitive Proximity Sensors Supplier in Bangladesh
E2K-L
Liquid Level Sensor That Is Unaffected by the Color of the Pipe or Liquid
Omron’s E2K-L capacitive proximity sensors provide highly reliable, non-contact liquid level monitoring specifically through bypass pipes and sight glasses. Because they utilize electrostatic capacitance, these sensors track levels accurately regardless of the color, opacity, or transparency of both the fluid and the pipe wall.
E2K-L sensors are engineered with space-saving built-in amplifiers and a specialized curved mounting face. They strap securely onto non-metallic tubes using included slip-proof bands, making them perfectly suited for fast, low-profile deployment in fluid processing and automated chemical systems.
E2K-L At A GLANCE
- Mount to bypass pipes.
- Fit a wide range of pipe diameters: 8 to 11 mm or 12 to 26 mm
- Built-in Amplifiers to save space.
Technical details-
Specifications
| Sensing head size | 33 mm |
|---|---|
| Sensing head size | 34 mm |
| Sensing head size | 20 mm |
| Type | Capacitive type |
| Type | Unshielded |
| Type | Square type |
| Power source | DC Three-wires models |
| Differential distance | 0.3 to 3 mm |
| Repetition precision | ±0.2 mm max. |
| Sensing object | Liquid |
| Power supply voltage | 12 to 24 VDC ripple (p-p) 10% max. |
| Operating voltage range | 10.8 to 30 VDC |
| Current consumption | 12 mA max. |
| Control output (Output type) | NPN open collector |
| Control output (Switching capacity) | 100 mA max. |
| Control output (Residual voltage) | 1 V max.(Load current 100 mA with cable length of 2 m) |
| Indicator | Detection indicator (orange) |
| Operation mode | NO |
| Sensitivity setting | Sensitivity adjuster |
| Ambient temperature (Operating) | 0 to 55 ℃ |
| Ambient temperature (Storage) | -10 to 65 ℃ |
| Ambient humidity (Operating) | 25 to 85% |
| Ambient humidity (Storage) | 25 to 85% |
| Temperature influence | ±4 mm of detection level at 23 ℃ in the temperature range of 0 to 55 ℃ (with pure water or 20% saline solution) |
| Voltage influence | ±0.5 mm of detection level at the rated voltage in rated voltage ±10% range |
| Insulation resistance | 50 MΩ min. at 500 VDC(Between charged parts and the case) |
| Dielectric strength | 500 VAC 50/60 Hz 1 min(Between charged parts and the case) |
| Vibration resistance | (Destruction) 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h |
| Shock resistance | (Destruction) 500 m/s**2 3 times each in X, Y and Z directions |
| Degree of protection | IP66(IEC) |
| Connection method | 2 m |
| Connection method | Pre-wired models |
| Weight | Approx. 70 g(Package) |
| Material | (Case) Heat-resistant ABS resin / (Cable clamp) NBR |
Datasheet: PDF
More Capacitive proximity sensors :
OMRON E2K-L13MC1 2M, OMRON E2K-L26MC2 2M
