OMRON Capacitive Proximity Sensors | E2K-X15MF1 2M
- Sensing distance: 15 mm ±10%
- Connection type: 2 m, Pre-wired models
- Switching output: PNP
- Output function: NO
- Switching frequency: 100 Hz
- Installation type: Unshielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
OMRON Capacitive Proximity Sensors | E2K-X15MF1 2M
OMRON Capacitive Proximity Sensors
OMRON Capacitive Proximity Sensors Supplier in Bangladesh
E2K-X
General-purpose Threaded Capacitive Sensor
Omron’s E2K-X capacitive proximity sensors permit non-contact detection of both metallic and non-metallic objects, seamlessly identifying glass, wood, water, oil, and plastic. Because they feature a fixed sensing distance, they require zero sensitivity adjustments for a quick, “plug-and-play” setup.
E2K-X sensors are enclosed in a rugged, heat-resistant ABS cylindrical housing with a threaded barrel design. Available in M12, M18, and M30 models, these sensors can be mounted securely in a wide variety of standard, everyday factory automation environments.
E2K-X At A GLANCE
- Product lineup with M12, M18, and M30 models.
- Fixed sensing distance requires no sensitivity adjustment.
Technical details-
Specifications
| Sensing head size | 60 mm |
|---|---|
| Sensing head size | M30 |
| Type | Capacitive type |
| Type | Unshielded |
| Type | Cylinder type (with screw) |
| Power source | DC Three-wires models |
| Sensing distance | 15 mm ±10% |
| Setting distance | 0 to 10 mm |
| Differential distance | 4 to 20% of sensing distance |
| Sensing object | Conductor and dielectrics |
| Standard sensing object | With grounded metal 50 x 50 x 1 mm |
| Response frequency | 100 Hz |
| Power supply voltage | 12 to 24 VDC |
| Operating voltage range | 10 to 30 VDC |
| Current consumption | 15 mA max. |
| Control output (Output type) | PNP |
| Control output (Switching capacity) | 200 mA max. |
| Control output (Residual voltage) | 2 V max.(Load current 200 mA with cable length of 2 m) |
| Indicator | Detection indicator (red) |
| Operation mode | NO |
| Protective circuit | Output short-cut protection;Output reverse polarity protection;Reverse polarity protection;Surge suppressor |
| Ambient temperature (Operating) | -10 to 55 ℃ |
| Ambient temperature (Storage) | -10 to 55 ℃ |
| Ambient humidity (Operating) | 35 to 95% |
| Ambient humidity (Storage) | 35 to 95% |
| Temperature influence | ±20% max. of sensing distance at 23 ℃ in the temperature range of -10 to 55 ℃ |
| Voltage influence | ±2% max. of sensing distance at rated voltage in the rated voltage ±20% range |
| Insulation resistance | 50 MΩ min. at 500 VDC(Between charged parts and the case) |
| Dielectric strength | 1,000 VAC 50/60 Hz 1 min(Between charged parts and the case) |
| Vibration resistance | (Destruction) 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h |
| Shock resistance | (Destruction) 500 m/s**2 3 times each in X, Y and Z directions |
| Degree of protection | IP66(IEC) / Oil-proof(Company standard) |
| Connection method | 2 m |
| Connection method | Pre-wired models |
| Weight | Approx. 205 g(Package) |
| Material | (Case) Heat-resistant ABS resin / (Sensing surface) Heat-resistant ABS resin / (Clamping nuts) Polyacetal |
| Accessories | Instruction manual |
Datasheet: PDF
