Sick CQF16-06EPOEP1

SICK Capacitive Proximity Sensors CQF16-06EPOEP1 | Part no: 6068625

  • Sensing range (max.): 0.5 mm – 6 mm
  • Connection type: Cable with M8 male connector, 4-pin, 0.3 m
  • Switching output: PNP
  • Output function: NC
  • Switching frequency: 10 Hz
  • Installation type: Flush/Non-flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SICK Capacitive Proximity Sensors CQF16-06EPOEP1 | Part no: 6068625

SICK Capacitive Proximity Sensors

SICK Capacitive Proximity Sensors Supplier in Bangladesh

CQF

Reliable level measurement of water-based liquids

The CQF capacitive level sensor detects liquids through container walls and through direct contact with the liquids. The measurement principle compensates for foam, moisture and deposits. This ensures that the CQF only detects the liquid in the container – nothing else. For standard applications, the sensor is ready for operation without additional settings. For challenging applications, it can be taught-in quickly and easily using the cable. The mounting set offers different installation options, making the CQF is well-suited for countless customer applications.



CQF AT A GLANCE
Benefits
  • Reliable level detection – compensation for foam, moisture and deposits
  • Flexible and straightforward installation – thanks to supplied mounting bracket
  • Quick commissioning – plug and play
  • Quick adaption to challenging applications – teach-in via cable
  • Space-saving compact housing, enclosure rating: IP67, IP68, IP69K
Features
  • Compact, rugged housing, enclosure rating: IP67, IP68, IP69K
  • Output signal: 100 mA, output type and function can be selected: PNP/NPN, N/O/N/C
  • Two LEDs for signaling voltage supply and output signal
  • Cable and cable with M8 male connector
  • Supplied mounting bracket
  • CULus certification
  • Ecolab certified

Technical details-

Features

Housing Rectangular
Dimensions (W x H x D) 16 mm x 34 mm x 8 mm
Sensing range Sn 0.5 mm … 6 mm
Installation type Flush

Non-flush
Switching frequency 10 Hz
Connection type Cable with M8 male connector, 4-pin, 0.3 m 1)
Switching output PNP
Switching output detail PNP
Output function NC
Electrical wiring DC 4-wire
Adjustment
Wire/pin Teach-in (full or empty)
Enclosure rating IP67, IP68, IP69K
Special features Detection of water-based liquids with conductivity up to 50 mS/cm; container diameter: min. 8 mm; container thickness: 0.5 mm … 6 mm (plastic), 0.5 mm … 4 mm (glass)
Items supplied Mounting bracket (1x)

1) Do not bend below 0 °C.

Mechanics & Electronics

Supply voltage 10 V … 30 V
Ripple ≤ 10 %
Voltage drop ≤ 1.5 V DC 1)
Current consumption 13 mA 2)
Time delay before availability ≤ 300 ms
Temperature drift (of Sr) ± 20 %
EMC EN 60947-5-2
Continuous current Ia ≤ 100 mA
Cable material PVC
Conductor size 0.14 mm²
Short-circuit protection ✔
Power-up pulse protection ✔
Shock and vibration resistance 30 g, 11 ms / 6 pos., 6 neg. per axis, 10 … 150 Hz, 1.0 mm / 15 g
Ambient operating temperature –25 °C … +80 °C
Ambient temperature, storage –40 °C … +85 °C
Housing material Plastic, PBT
Tightening torque, max. 0.2 Nm
Protection class III
UL File No. NRKH.E191603

1) At Ia max.

2) Without load.

Datasheet: PDF

More Capacitive proximity sensors :

SICK CQF16-06EPSEW1 (6068622), SICK CQF16-06EPOEW1 (6068623), SICK CQF16-06EPSEP1 (6068624), SICK CQF16-06ENSEP1 (6068628), SICK CQF16-06ENSEW1 (6068626), SICK CQF16-06ENOEW1 (6068627), SICK CQF16-06ENOEP1 (6068629)
