SICK Photoelectric Sensors VTE18L-4N344 | Part no: 6027424
- Functional principle: Photoelectric proximity sensor
- Sensing range (max.): 2 mm – 250 mm
- Connection type: Male connector M12, 4-pin
- Output Type: NPN
- Switching frequency: 800 Hz
- Switching mode: Light/dark switching
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Photoelectric Sensors VTE18L-4N344 | Part no: 6027424
SICK Photoelectric Sensors
SICK Photoelectric Sensors Supplier in Bangladesh
V18
Laser sensor in cylindrical M18 housing
The V18 Laser family of photoelectric sensors offers modern laser technology with a small, highly visible light spot that detects small parts and offers precise sensing. These laser class 1 sensors provide long sensing distances and short response times.
Yellow and green indicator LEDs ensure easy mounting, commissioning, adjustment and maintenance. Sensitivity can be set in several ways – either manually via a teach-in pushbutton or electronically using control input C.
V18 AT A GLANCE
- Laser sensor in cylindrical M18 housing lowers installation costs
- Time-saving installation and commissioning due to clearly visible light spot
- Laser class 1 does not require any enhanced safety measures or labeling, which lowers installation costs
- Quick response time ensures reliable object detection at high speeds, which increases the machine’s throughput
- Laser emitter LED enclosed in a cylindrical M18 housing
- Laser class 1
- Fast response time
- Straight or right-angle housing
- Durable metal housing
- IP 67
- Small visible light spot to detect small objects
Technical details-
Features
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Energetic |
| Dimensions (W x H x D) | 18 mm x 18 mm x 107.7 mm |
| Housing design (light emission) | Cylindrical |
| Housing length | 107.7 mm |
| Thread diameter (housing) | M18 x 1 |
| Optical axis | Radial |
| Sensing range max. | 2 mm … 250 mm 1) |
| Sensing range | 5 mm … 200 mm |
| Type of light | Visible red light |
| Light source | Laser 2) |
| Light spot size (distance) | Ø 5 mm (200 mm) |
| Wave length | 650 nm |
| Laser class | 1 (IEC 60825-1) 3) |
| Laser power output | 0.4 mW |
| Adjustment | Cable, Single teach-in button (Sensing range, Sensing range) 4) 5) |
| Special feature | Focused optics |
| Special applications | Detecting small objects |
1) Object with 90% remission (based on standard white, DIN 5033).
2) Average service life: 100,000 h at TU = +25 °C.
3) Do not intentionally look into the laser beam. Never point the laser beam at people’s eyes.
4) Electronically via control input C (0 V).
5) Manual, via teach-in button.
Mechanics/Electronics
| Supply voltage UB | 10 V DC … 30 V DC 1) |
| Ripple | ± 10 % 2) |
| Current consumption | 30 mA 3) |
| Switching output | NPN |
| Switching mode | Light/dark switching |
| Switching mode selector | Selectable via control input C |
| Output current Imax. | ≤ 100 mA |
| Response time | ≤ 0.625 ms 4) |
| Switching frequency | 800 Hz 5) |
| Connection type | Male connector M12, 4-pin |
| Circuit protection | A 6)
B 7) C 8) D 9) |
| Protection class | III |
| Weight | 60 g |
| Housing material | Metal, Nickel-plated brass/PC |
| Optics material | Plastic, PC with protective glass pane |
| Enclosure rating | IP67 |
| Special feature | Focused optics |
| Ambient operating temperature | –15 °C … +55 °C |
| Ambient temperature, storage | –25 °C … +70 °C |
| UL File No. | NRKH.E181493, CDRH-conform (0312012-00) |
1) Limit values.
2) May not fall below or exceed UV tolerances.
3) Without load.
4) Signal transit time with resistive load.
5) With light/dark ratio 1:1.
6) A = VS connections reverse-polarity protected.
7) B = inputs and output reverse-polarity protected.
8) C = interference suppression.
9) D = outputs overcurrent and short-circuit protected.
Datasheet: PDF
