SICK RAY26P-34112C30ZZZ

SICK Photoelectric Sensors RAY26P-34112C30ZZZ | Part no: 1121282

  • Functional principle: Photoelectric retro-reflective sensor
  • Sensing range (max.): 0 m – 1.5 m
  • Connection type: Cable with M12 male connector, 4-pin, 270 mm
  • Output Type: PNP/NPN
  • Switching frequency: 1000 Hz
  • Switching mode: Light/dark switching



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SICK Photoelectric Sensors RAY26P-34112C30ZZZ | Part no: 1121282

SICK Photoelectric Sensors

SICK Photoelectric Sensors Supplier in Bangladesh

RAY26 Reflex Array

Photoelectric sensor with light array for detecting flat objects

Photoelectric sensors from the RAY26 Reflex Array product family enable reliable object detection of flat objects as well as fast commissioning. When combined with a reflector, the photoelectric sensors also detect small, flat, transparent or uneven objects from a size of 3 mm (1mm). Within a 55 mm (20 mm)-high uniform light array, the sensors detect the leading edge of the respective object for this purpose. This means that even perforated objects can be reliably detected without multiple switching.





RAY26 Reflex Array AT A GLANCE

Benefits
  • Reduce overall costs by up to 50% compared to solutions with separate sender and receiver housings
  • Reliable, position-independent detection of very flat objects
  • Productivity increase thanks to reliable object detection (regardless of object property) and prevention of multiple switching (for perforated, non-uniform objects)
  • Quick and easy optical alignment, commissioning and monitoring
  • Reduction of downtime of conveyor systems
Features
  • Sender and receiver in a single housing, combined with a reflector
  • Detection of objects > 1 mm or > 3, 5, 10 mm, depending on the detection height
  • ASIC from SICK
  • Visible uniform light array (PinPoint LED)
  • AutoAdapt technology (predictive maintenance) and conveyor belt suppression

Technical details-

Features

Functional principle Photoelectric retro-reflective sensor
Functional principle detail Without reflector minimum distance (autocollimation/coaxial optics), Reflex Array
Dimensions (W x H x D) 24.6 mm x 82.5 mm x 53.3 mm
Housing design (light emission) Rectangular
Minimum object size 2 mm, position-independent detection within the light array
Detection height 10 mm
Sensing range max. 0 m … 1.5 m 1) 2)
Distance of the sensor to reflector ≥ 0 m
Type of light Visible red light
Light source PinPoint LED 3)
Light spot size (distance) 10 mm x 9 mm (1 m)
Wave length 635 nm
Adjustment BluePilot: Teach-in
AutoAdapt ✔
Special applications Detecting objects with position tolerances, Detecting perforated objects, Detecting uneven, shiny objects, Detecting transparent objects, Detecting flat objects

1) Reflector PL80A.

2) At minimum object size 10 mm.

3) Average service life: 100,000 h at TU = +25 °C.

Mechanics/Electronics

Supply voltage UB 10 V DC … 30 V DC 1)
Ripple < 5 Vpp
Current consumption 25 mA 2)

40 mA 3)
Switching output Push-pull: PNP/NPN 4)
Output function Factory setting: Pin 2 / white: NPN normally closed (light switching), PNP normally open (dark switching), Pin 4 / black: NPN normally open (dark switching), PNP normally closed (light switching)
Switching mode Light/dark switching
Signal voltage PNP HIGH/LOW Approx. VS – 2.5 V / 0 V
Signal voltage NPN HIGH/LOW Approx. VS / < 2.5 V
Output current Imax. ≤ 100 mA
Response time ≤ 500 µs 5)
Switching frequency 1,000 Hz 6)
Connection type Cable with M12 male connector, 4-pin, 270 mm 7)
Cable material Plastic, PVC
Circuit protection A 8)

B 9)

C 10)

D 11)
Protection class III
Weight 100 g
Housing material Plastic, VISTAL®
Optics material Plastic, PMMA
Enclosure rating IP66

IP67
Ambient operating temperature –40 °C … +60 °C 12) 13)
Ambient temperature, storage –40 °C … +75 °C
UL File No. NRKH.E181493 & NRKH7.E181493

1) Limit values.

2) 16 V DC … 30 V DC, without load.

3) 10 V DC … 16 V DC, without load.

4) Pin 4 and pin 2: This switching output must not be connected to another output.

5) Signal transit time with resistive load in switching mode.

6) With light/dark ratio 1:1 in switching mode.

7) Do not bend below 0 °C.

8) A = VS connections reverse-polarity protected.

9) B = inputs and output reverse-polarity protected.

10) C = interference suppression.

11) D = outputs overcurrent and short-circuit protected.

12) Avoid condensation on the front screen of the sensor and on the reflector.

13) Allowed temperature change after Teach +/- 20 K.

Datasheet: PDF

More Photoelectric sensors :

SICK RAY26P-1H161930A00 Part No: 1222342, SICK RAY26P-34862930A00 Part No: 1121370, SICK RAY26P-1H162530A00 Part No: 1221948, SICK RAY26P-1H162330A00 Part No: 1221945, SICK RAY26P-34162530A00 Part No: 1221947, SICK RAY26P-34161530A00 Part No: 1222341, SICK RAY26P-24162130A00 Part No: 1106993, SICK RAY26P-34862330A00 Part No: 1120665, SICK RAY26P-1H161530A00 Part No: 1222343, SICK RAY26P-24862130A00 Part No: 1120666, SICK RAY26P-34162930A00 Part No: 1221950, SICK RAY26P-1H162930A00 Part No: 1221951, SICK RAY26P-24162330A00 Part No: 1221060, SICK RAY26P-34137B30ZZZ Part No: 1121281, SICK RAY26P-34862530A00 Part No: 1121881, SICK RAY26P-34161930A00 Part No: 1222340, SICK RAY26P-24162530A00 Part No: 1221946, SICK RAY26P-34162130A00 Part No: 1106994, SICK RAY26P-34162A30A00 Part No: 1113471, SICK RAY26P-24162930A00 Part No: 1221949, SICK RAY26P-P05 Part No: 1144541, SICK RAY26P-34162330A00 Part No: 1221943, SICK RAY26P-34162A30A00 Part No: 1111102, SICK RAY26P-P01 Part No: 1109011
