SICK Capacitive Proximity Sensors CQ35-25NPP-KW1 | Part no: 6020478
- Sensing range (max.): 4 mm – 25 mm
- Connection type: Cable, 4-wire, 2 m
- Switching output: PNP
- Output function: Complementary
- Switching frequency: 50 Hz
- Installation type: Non-flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Capacitive Proximity Sensors CQ35-25NPP-KW1 | Part no: 6020478
SICK Capacitive Proximity Sensors
SICK Capacitive Proximity Sensors Supplier in Bangladesh
CQ
Reliable capacitive proximity sensors enclosed in a rectangular housing
Capacitive proximity sensors can detect all types of material: powder-based, granulated, liquid, and solid – even through plastic walls. SICK’s capacitive proximity sensors also feature high electromagnetic compatibility (EMC), which prevents incorrect switching.
CQ sensors feature rectangular housings that are suitable for all manner of installation conditions.
- Non-contact level measurement, even through container or tank walls, which eliminates drilling holes and thus reduces installation time
- Durable housing withstands harsh industrial applications, reducing maintenance costs
- Quick and easy adjustment of the switching point – via pushbutton, remote teach for the CQ28 and via potentiometer for CQ35 – saves time
- Simple and safe detection alternative to photoelectric and inductive sensors in applications such as detecting product in a sealed box, container or tank
- Rectangular housing
- Detects powders, granulates, liquids and solids
- Extremely high electromagnetic compatibility
- Electric version: DC, 4 cables
- Supply voltage: 10 V … 36 V DC
- Short-circuit protection (pulsed)
Technical details-
Features
| Housing | Rectangular | ||||
| Dimensions (W x H x D) | 35 mm x 69.5 mm x 15 mm | ||||
| Sensing range Sn | 4 mm … 25 mm | ||||
| Safe sensing range Sa | 18 mm | ||||
| Installation type | Non-flush | ||||
| Switching frequency | 50 Hz | ||||
| Connection type | Cable, 4-wire, 2 m 1) | ||||
| Switching output | PNP | ||||
| Switching output detail | PNP | ||||
| Output function | Complementary | ||||
| Electrical wiring | DC 4-wire | ||||
|
|||||
| Enclosure rating | IP67 2) | ||||
| Items supplied | Screwdriver for potentiometer adjustment (1 x) | ||||
1) Do not bend below 0 °C.
2) According to EN 60529.
Mechanics & Electronics
| Supply voltage | 10 V DC … 36 V DC |
| Ripple | ≤ 10 % 1) |
| Voltage drop | ≤ 2.5 V DC 2) |
| Current consumption | 10 mA 3) |
| Time delay before availability | ≤ 100 ms |
| Hysteresis | 4 % … 20 % |
| Reproducibility | ≤ 5 % 4)
5) |
| Temperature drift (of Sr) | ± 10 % |
| EMC | According to EN 60947-5-2 6) |
| Continuous current Ia | ≤ 200 mA |
| Cable material | PVC |
| Conductor size | 0.34 mm² |
| Short-circuit protection | ✔ |
| Power-up pulse protection | ✔ |
| Shock and vibration resistance | 30 g, 11 ms / 10 … 55 Hz, 1 mm |
| Ambient operating temperature | –25 °C … +75 °C |
| Housing material | Plastic, PC |
| Sensing face material | Plastic |
| UL File No. | NRKH.E191603 |
1) Of Ub.
2) At Ia max.
3) Without load.
4) Of Sr.
5) Supply voltage UB and constant ambient temperature Ta.
6) In EMC critical applications, conducted interference levels may lie within the frequency range of the oscillator. This can cause changes to the output signal. (See operating instructions.).
Datasheet: PDF
