SICK Inductive Proximity Sensors IM30-15N-N-ZW0 | Part no: 6021129
- Sensing range (max.): 15 mm
- Connection type: Cable, 2-wire, 2 m
- Switching output: NAMUR
- Output function: NC
- Switching frequency: 200 Hz
- Installation type: Non-flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Inductive Proximity Sensors IM30-15N-N-ZW0 | Part no: 6021129
SICK Inductive Proximity Sensors
SICK Inductive Proximity Sensors Supplier in Bangladesh
IMN
Inductive NAMUR sensors for Ex zones
Safe detection in ATEX areas. The IMN sensors are available for this due to their high quality and reliability. No whether in category 1G or 2G, the NAMUR sensors from SICK are perfectly suited for explosion-hazardous areas.
- Exceptional protection in explosive areas
- Category 1G and 2G for zones 0 and 1
- Output according to DIN EN 60947-5-6
- Types: M8 to M30
- Sensing ranges: 1 mm to 15 mm
- NAMUR according to DIN EN 60947-5-6
- Enclosure rating: IP67
- Temperature range: –20 °C to +70 °C
- Nickel-plated brass housing; plastic sensing face
- ATEX device category 1G and 2G
- Suitable for applications in explosion-hazardous areas
Technical details-
Features
| Housing | Metric |
| Thread size | M30 x 1.5 |
| Diameter | Ø 30 mm |
| Sensing range Sn | 15 mm |
| Safe sensing range Sa | 12.15 mm |
| Installation type | Non-flush |
| Switching frequency | 200 Hz |
| Connection type | Cable, 2-wire, 2 m |
| Switching output | NAMUR |
| Switching output detail | NAMUR |
| Output function | NC |
| Enclosure rating | IP67 1) |
| Special features | ATEX |
| Special applications | Explosive areas |
| Items supplied | Mounting nut, brass, nickel-plated (2x) |
1) According to EN 60529.
Mechanics & Electronics
| Supply voltage | 7.5 V DC … 25 V DC 1) |
| Hysteresis | 1 % … 15 % |
| Temperature drift (of Sr) | ± 10 % |
| EMC | According to EN 60947-5-6 |
| Current consumption, sensor is activated | ≤ 1 mA |
| Current consumption, sensor is not activated | ≥ 2.2 mA |
| Cable material | PVC |
| Conductor size | 0.5 mm² |
| Cable diameter | Ø 5.4 mm |
| Cable resistance | 50 Ω |
| Shock and vibration resistance | 30 g, 11 ms / 10 … 55 Hz, 1 mm |
| Ambient operating temperature | –20 °C … +70 °C |
| Housing material | Brass, nickel-plated |
| Sensing face material | Plastic, PTB |
| Housing length | 41 mm |
| Thread length | 25 mm |
| Tightening torque, max. | ≤ 50 Nm |
| Weight | + 220 g |
| Type approval certificate | PTB 03 ATEX 2037 |
| Ex area category | 1G, 2G |
| Input voltage Ui max. | 15 V 2) |
| Input power Pi max. | 120 mW 2) |
| Input current Ii max. | 50 mA 2) |
| Internal capacitance Ci max. | 145 nF 2) |
| Internal inductance Li max. | 110 µH 2) |
| Nominal voltage | 8.2 V DC 3) |
| Device labeling | II 1G Ex ia IIC T6 Ga Ta –20 °C … +70 °C, II 2 G Ex ia IIC T6 Gb Ta: –20 °C … +70 °C |
1) When used outside the hazardous area.
2) For connection to a separately certified intrinsically safe circuit only.
3) 1 kΩ.
Datasheet: PDF
