Omron E2A-S12LS04-WP-B1

Omron Inductive Proximity Sensor E2A-S12LS04-WP-B1 2M

  • Output Type: PNP
  • Operation Mode: NO
  • Sensing Distance: 4mm
  • Mounting Type: Flush
Category:
Tags:

Description

Omron Inductive Proximity Sensor E2A-S12LS04-WP-B1 2M

Inductive Proximity Sensor

E2A-S

Extended sensing range inductive sensor in cylindrical stainless steel housing

The performance and operational reliability of the E2A family is also available in stainless steel housing.

Inductive proximity sensor E2A-S was created and tested for applications in the harsh environment and at though vibration conditions with stainless body.

• M8, M12, M18, and M30 housings with connector or pre-wired connection

• PNP or NPN output

• NO, NC, or NO+NC operation mode

Specifications

Size M12
Mounting type Flush
Sensing distance 4 mm
Output type PNP
Operation mode NO
Connection method Cable
Material housing Stainless steel
Cable specifications PVC
Cable length 2 m
Overall length of sensor 72 mm
Thread length 56 mm

Omron E2A-S Series Product Lineup:

Product Size Mounting Type Sensing Distance
E2A-S08KN02-M1-B1 M8 Non-flush 2 mm
E2A-S08KN04-M1-B1 M8 Non-flush 4 mm
E2A-S08KN04-M1-B2 M8 Non-flush 4 mm
E2A-S08KN04-M3-B1 M8 Non-flush 4 mm
E2A-S08KN04-M5-B1 M8 Non-flush 4 mm
E2A-S08KN04-M5-B2 M8 Non-flush 4 mm
E2A-S08KN04-WP-B1 2M M8 Non-flush 4 mm
E2A-S08KN04-WP-B1 5M M8 Non-flush 4 mm
E2A-S08KN04-WP-B2 2M M8 Non-flush 4 mm
E2A-S08KN04-WP-C1 2M M8 Non-flush 4 mm
E2A-S08KS01-WP-C1 2M M8 Flush 1 mm
E2A-S08KS02-M1-B1 M8 Flush 2 mm
E2A-S08KS02-M1-B2 M8 Flush 2 mm
E2A-S08KS02-M1-C1 M8 Flush 2 mm
E2A-S08KS02-M3-B1 M8 Flush 2 mm
E2A-S08KS02-M3-B2 M8 Flush 2 mm
E2A-S08KS02-M5-B1 M8 Flush 2 mm
E2A-S08KS02-M5-B2 M8 Flush 2 mm
E2A-S08KS02-M5-C1 M8 Flush 2 mm
E2A-S08KS02-WP-B1 2M M8 Flush 2 mm
E2A-S08KS02-WP-B1 5M M8 Flush 2 mm
E2A-S08KS02-WP-B2 2M M8 Flush 2 mm
E2A-S08KS02-WP-C1 2M M8 Flush 2 mm
E2A-S08KS02-WP-C1 5M M8 Flush 2 mm
E2A-S08KS02-WP-C2 2M M8 Flush 2 mm
E2A-S08KS02-WP-D1 2M M8 Flush 2 mm
E2A-S08LN04-M1-B1 M8 Non-flush 4 mm
E2A-S08LN04-M3-B3 M8 Non-flush 4 mm
E2A-S08LN04-M5-B1 M8 Non-flush 4 mm
E2A-S08LN04-WP-B1 2M M8 Non-flush 4 mm
E2A-S08LS01-M1-B1 M8 Flush 1 mm
E2A-S08LS02-M1-B1 M8 Flush 2 mm
E2A-S08LS02-M1-B2 M8 Flush 2 mm
E2A-S08LS02-M1-C1 M8 Flush 2 mm
E2A-S08LS02-M3-B1 M8 Flush 2 mm
E2A-S08LS02-M3-B3 M8 Flush 2 mm
E2A-S08LS02-M5-B1 M8 Flush 2 mm
E2A-S08LS02-M5-B2 M8 Flush 2 mm
E2A-S08LS02-M5-C1 M8 Flush 2 mm
E2A-S08LS02-WP-B1 2M M8 Flush 2 mm
E2A-S08LS02-WP-B1 5M M8 Flush 2 mm
E2A-S08LS02-WP-C1 2M M8 Flush 2 mm
E2A-S12KN08-M1-B1 M12 Non-flush 8 mm
E2A-S12KN08-WP-B1 2M M12 Non-flush 8 mm
E2A-S12KS04-M1-B1 M12 Flush 4 mm
E2A-S12KS04-M1-B2 M12 Flush 4 mm
E2A-S12KS04-M1-C1 M12 Flush 4 mm
E2A-S12KS04-WP-B1 2M M12 Flush 4 mm
E2A-S12KS04-WP-B1 5M M12 Flush 4 mm
E2A-S12KS04-WP-B2 2M M12 Flush 4 mm
E2A-S12KS04-WP-C1 2M M12 Flush 4 mm
E2A-S12LS04-M1-B1 M12 Flush 4 mm
E2A-S12LS04-WP-B1 2M M12 Flush 4 mm
E2A-S18KN16-M1-B1 M18 Non-flush 16 mm
E2A-S18KN16-WP-B1 2M M18 Non-flush 16 mm
E2A-S18KS08-M1-B1 M18 Flush 8 mm
E2A-S18KS08-M1-B2 M18 Flush 8 mm
E2A-S18KS08-WP-B1 2M M18 Flush 8 mm
E2A-S18KS08-WP-B1 5M M18 Flush 8 mm
E2A-S18LS08-M1-B1 M18 Flush 8 mm
E2A-S30KS15-M1-B1 M30 Flush 15 mm



Data Sheet: PDF
