OMRON Capacitive Proximity Sensors | E2KQ-X10ME1 2M
- Sensing distance: 10 mm
- Connection type: 2 m, Pre-wired models
- Switching output: NPN
- Output function: NO
- Switching frequency: 35 Hz
- Installation type: Unshielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
OMRON Capacitive Proximity Sensors | E2KQ-X10ME1 2M
OMRON Capacitive Proximity Sensors
OMRON Capacitive Proximity Sensors Supplier in Bangladesh
E2KQ-X
Fluororesin-coated Capacitive Sensor with Sensitivity Adjuster
Omron’s E2KQ-X capacitive proximity sensors deliver highly dependable, non-contact detection across a broad spectrum of metallic and non-metallic objects, including dielectrics, liquids, and bulk solids. Outfitted with a manual sensitivity adjustment screw, these sensors can be customized on-the-fly to establish an optimal sensing range based on the unique electrical and water-content profile of your target material.
E2KQ-X sensors feature threaded M18 cylindrical housings constructed entirely from a premium fluorine resin (fluororesin). This unique coating provides elite resistance against corrosive chemicals, industrial oils, and machining fluids, ensuring reliable and secure installation in harsh semiconductor manufacturing and chemical processing environments.
E2KQ-X At A GLANCE
- Excellent resistance against chemicals and oil with fluororesincoated case.
- Distance adjustment according to the sensing object using the sensitivity adjuster.
Technical details-
Specifications
| Sensing head size | 61.8 mm |
|---|---|
| Sensing head size | M18 |
| Type | Capacitive type |
| Type | Unshielded |
| Type | Cylinder type (with screw) |
| Power source | DC Three-wires models |
| Sensing distance | 10 mm |
| Setting distance | 6 to 10 mm |
| Differential distance | 4 to 20% of sensing distance |
| Sensing object | Conductor and dielectrics |
| Standard sensing object | With grounded metal 50 x 50 x 1 mm |
| Response frequency | 35 Hz |
| Power supply voltage | 12 to 24 VDCripple (p-p) 10% max. |
| Operating voltage range | 10 to 30 VDC |
| Current consumption | 15 mA max. |
| Control output (Output type) | NPN |
| Control output (Switching capacity) | 100 mA max. |
| Control output (Residual voltage) | 1.5 V max.(Load current 100 mA with cable length of 2 m) |
| Indicator | Detection indicator (red) |
| Operation mode | NO |
| Sensitivity setting | Sensitivity adjuster |
| Protective circuit | Reverse polarity protection;Surge suppressor |
| Ambient temperature (Operating) | -10 to 55 ℃ |
| Ambient temperature (Storage) | -25 to 55 ℃ |
| Ambient humidity (Operating) | 35 to 85% |
| Ambient humidity (Storage) | 35 to 85% |
| Temperature influence | ±15% max. of sensing distance at 23 ℃ in the temperature range of −10 to 55 ℃ |
| Voltage influence | ±2% max. of sensing distance at rated voltage in the rated voltage ±20% range |
| Insulation resistance | 50 MΩ min. at 500 VDC(Between charged parts and the case) |
| Dielectric strength | 500 VAC 50/60 Hz 1 min(Between charged parts and the case) |
| Vibration resistance | (Destruction) 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h |
| Shock resistance | (Destruction) 500 m/s**2 3 times each in X, Y and Z directions |
| Degree of protection | IP66(IEC) / Oil-proof(Company standard) |
| Connection method | 2 m |
| Connection method | Pre-wired models |
| Weight | Approx. 150 g(Package) |
| Material | (Case) Fluoride resin / (Sensing surface) Fluoride resin / (Cable) PVC / (Clamping nuts) Fluoride resin |
| Accessories | Instruction manual;Adjustment Driver |
