Leuze Polarized Retro-Reflective Photoelectric Sensor PRK3CL1.A3/6-M8.3, 50141749
- RANGE: 0-3m.
- PNP(LIGHT SWITCHING).
- NPN (DARK SWITCHING).
- SUPPLY VOLTAGE: 10-30 VDC.
- M8 CONNECTOR.
- 3-PIN.
- PLASTIC HOUSING.
Description
Leuze Polarized Retro-Reflective Photoelectric Sensor PRK3CL1.A3/6-M8.3, 50141749
Leuze PRK3CL1.A3/6-M8.3, 50141749
Retro-reflective photoelectric sensors
Technical features:-
Basic Data:-
| Series | 3C |
| Operating principle | Reflection principle |
Special Version:-
| Special version | Autocollimation |
Optical Data:-
| Operating range | 0 … 2 m (guaranteed operating range), With reflector MTKS 50×50.1 |
| Operating range limit | 0 … 3 m (typical operating range), With reflector MTKS 50×50.1 |
| Beam path | Collimated |
| Light source | Laser, Red |
| Wavelength | 655 nm |
| Laser class | 1, in accordance with IEC 60825-1:2014 (EN 60825-1:2014) |
| Max. laser power | 0.0017 W |
| Transmitted-signal shape | Pulsed |
| Pulse duration | 5.3 µs |
| Light spot size [at sensor distance] | 3 mm [1,000 mm] |
| Type of light spot geometry | Round |
| Shift angle | Typ. ± 2° |
Electrical Data:-
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC, Incl. residual ripple |
| Residual ripple | 0 … 15 %, From UB |
| Open-circuit current | 0 … 15 mA |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs:-
| Type | Digital switching output |
Switching Outputs 1:-
| Switching element | Transistor, Push-pull |
| Switching principle | Light switching (PNP)/dark switching (NPN) |
Time Behavior:-
| Switching frequency | 3,000 Hz |
| Response time | 0.17 ms |
| Readiness delay | 300 ms |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Connector |
| Thread size | M8 |
| Type | Male |
| Material | Metal |
| No. of pins | 3 -pin |
Mechanical Data:-
| Dimension (W x H x L) | 11.4 mm x 34.2 mm x 18.3 mm |
| Housing material | Plastic |
| Plastic housing | PC-ABS |
| Lens cover material | Plastic / PMMA |
| Net weight | 10 g |
| Housing color | Red |
| Type of fastening | Through-hole mounting Via optional mounting device |
| Compatibility of materials | ECOLAB |
Operation & Display:-
| Type of display | LED |
| Operational controls | Teach button |
| Function of the operational control | Sensitivity adjustment |
Environmental Data:-
| Ambient temperature, operation | -40 … 55 °C |
| Ambient temperature, storage | -40 … 70 °C |
Data Sheet: Pdf
