Leuze Polarized Retro-Reflective Photoelectric Sensor PRK25C.D1/4P-200-M12, 50134298
- RANGE: 0.05-8m.
- PNP (LIGHT SWITCHING/DARK SWITCHING).
- SUPPLY VOLTAGE: 10-30 VDC.
- CABLE WITH CONNECTOR 200mm.
- 4-PIN.
- PLASTIC HOUSING.
Description
Leuze Polarized Retro-Reflective Photoelectric Sensor PRK25C.D1/4P-200-M12, 50134298
Leuze PRK25C.D1/4P-200-M12, 50134298
Retro-reflective photoelectric sensors
Technical features:-
Basic Data:-
| Series | 25C |
| Operating principle | Reflection principle |
| Application | Detection of stretch-wrapped objects |
Optical Data:-
| Operating range | 0.05 … 8 m (guaranteed operating range), With reflector TK(S) 100×100 |
| Operating range limit | 0.05 … 10 m (typical operating range), With reflector TK(S) 100×100 |
| Light source | LED, Red |
| Wavelength | 640 nm |
| Transmitted-signal shape | Pulsed |
| LED group | Exempt group (in acc. with EN 62471) |
Electrical Data:-
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC, Incl. residual ripple |
| Residual ripple | 0 … 15 %, From UB |
| Open-circuit current | 0 … 20 mA |
Outputs:-
| Number of digital switching outputs | 2 Piece(s) |
Switching Outputs:-
| Type | Digital switching output |
Switching Outputs 1:-
| Switching element | Transistor, PNP |
| Switching principle | Light switching |
Switching Outputs 2:-
| Switching element | Transistor, PNP |
| Switching principle | Dark switching |
Time Behavior:-
| Switching frequency | 1,500 Hz |
| Response time | 0.33 ms |
| Readiness delay | 300 ms |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Cable with connector |
| Cable length | 200 mm |
| Sheathing material | PUR |
| Cable color | Black |
| Wire cross section | 0.2 mm² |
| Thread size | M12 |
| Type | Male |
| Material | PUR |
| No. of pins | 4 -pin |
| Encoding | A-coded |
Mechanical Data:-
| Dimension (W x H x L) | 15 mm x 42.7 mm x 30 mm |
| Housing material | Plastic |
| Plastic housing | ABS |
| Lens cover material | Plastic |
| Net weight | 33 g |
| Housing color | Red |
| Type of fastening | Through-hole mounting with M4 thread Via optional mounting device |
| Compatibility of materials | ECOLAB |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 2 Piece(s) |
| Operational controls | 270° potentiometer |
| Function of the operational control | Sensitivity adjustment |
Environmental Data:-
| Ambient temperature, operation | -40 … 60 °C |
| Ambient temperature, storage | -40 … 70 °C |
Data Sheet: Pdf
