Leuze 50139560

Leuze Diffuse Sensor With Background Suppression HT25C/6G-200-M8 | 50139560

  • RANGE: 0-1.2 m
  • OUTPUT: PNP/NPN(LIGHT SWITCHING/DARK SWITCHING)
  • SUPPLY VOLTAGE: 10-30VDC
  • Cable With M8 Connector
  • IP 67, IP 69K
Category:
Tag:

Description

Leuze Diffuse Sensor With Background Suppression HT25C/6G-200-M8 | 50139560

Leuze HT25C/6G-200-M8 | 50139560

Leuze Diffuse Sensors

Transmitter and receiver in one housing: Detection performed by detecting the light reflected by the object.

Technical Features:-

Basic Data:-

Series 25C
Operating principle Diffuse reflection principle with background suppression

Optical Data:-

Black-white error < 10% up to 400 mm
Operating range Guaranteed operating range
Operating range, white 90% 0 … 1.2 m
Operating range, gray 18% 0.005 … 0.75 m
Operating range, black 6% 0.005 … 0.65 m
Operating range limit 0 … 1.2 m
Operating range limit Typical operating range
Adjustment range 50 … 1,200 mm
Light source LED, Red
Wavelength 640 nm
Transmitted-signal shape Pulsed
LED group Exempt group (in acc. with EN 62471)

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC, Incl. residual ripple
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 20 mA

Outputs:-

Number of digital switching outputs 2 Piece(s)

Switching Outputs:-

Type Digital switching output

Switching Outputs 1:-

Switching element Transistor, Push-pull
Switching principle Light switching (PNP)/dark switching (NPN)

Switching Outputs 2:-

Switching element Transistor, Push-pull
Switching principle Dark switching (PNP)/light switching (NPN)

Time Behavior:-

Switching frequency 1,000 Hz
Response time 0.5 ms
Readiness delay 300 ms

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable with connector
Cable length 200 mm
Sheathing material PUR
Cable color Black
Wire cross section 0.2 mm²
Thread size M8
Type Male
Material PUR
No. of pins 4 -pin

Mechanical Data:-

Dimension (W x H x L) 15 mm x 42.7 mm x 30 mm
Housing material Plastic
Plastic housing ABS
Lens cover material Plastic
Net weight 33 g
Housing color Red
Type of fastening Through-hole mounting with M4 thread
Via optional mounting device
Compatibility of materials ECOLAB

Operation & Display:-

Type of display LED
Number of LEDs 2 Piece(s)
Operational controls Multiturn potentiometer
Function of the operational control Range adjustment

Environmental Data:-

Ambient temperature, operation -40 … 60 °C
Ambient temperature, storage -40 … 70 °C

Data Sheet: PDF
