Krohne OPTIFLUX 4100

KROHNE Electromagnetic Flowmeter OPTIFLUX 4100

For Price Call: 01329727092
Email: sales@voltecbd.com



Category:
Tags:

Description

KROHNE Electromagnetic Flowmeter OPTIFLUX 4100

KROHNE OPTIFLUX 4100

Krohne Flow Meter Supplier in Bangladesh

Electromagnetic flowmeter for standard applications with abrasive and aggressive liquids

  • Chemically resistant, for liquids (>5 μS/cm) with solid content (≤10%)
  • Up to +180°C / +356°F
  • Flange: DN2.5…1200 / ⅒…48″, max. PN40 / ASME Cl 600
  • 4…20 mA, pulse, frequency, status, HART®

Overview

The OPTIFLUX 4100 is an electromagnetic flowmeter (EMF) for a wide range of standard process applications with aggressive and abrasive liquids. It enables reliable flow measurement even under harsh process conditions with temperatures up to +180°C / +356°F, low conductivity (≥5 µS/cm) and solid content (up to 10%). This makes the flowmeter particularly suitable for applications involving corrosive chemicals, sewage and drilling mud or mining sludge. Installation in measurement chambers subject to (constant) flooding is also possible using the optional IP68 / NEMA 6P rated version.

Features & Options

Product features and options depend on device configuration: Contact us to make sure that your preferred functionality can be combined in one device.



  • Bi-directional flow measurement over a wide dynamic range (turndown ratio: 1000:1)
  • PTFE, PFA, ETFE, hard rubber, soft rubber or PU liner: excellent chemical and abrasion resistance
  • Wide range of electrode materials
  • Special designs, sizes, inner diameters and liner thicknesses on request
  • Standard measurement accuracy: ±0.3% or ±1mm/s of measured value (MV)
  • Optional external coatings for offshore or subsoil installation (also acc. to ISO 12944)
  • Diagnostics incl. conductivity, electrode error, ambient and process temperature etc.
  • Full bore design: No moving parts, no wear, no pressure loss
  • For hazardous areas: ATEX, IECEx, FM, CSA
  • On-site verification of flowmeter with OPTICHECK service tool

Typical applications

General

  • Standard applications with clean, aggressive or abrasive liquids

Chemical and other process industries

  • Conductive fluid chemicals
  • Process water, cooling water

Oil and gas industry

  • Water injection (high pressure)
  • Drilling mud
  • Produced water

Minerals and mining industry

  • Hydrocyclone feed lines

Pulp and paper industry

  • Chemicals (black liquor, bleach, etc.)

Wastewater industry

  • Irrigation
  • Sludge and sewage treatment

Specifications

Depending on selected device configuration

General information

Product type Flowmeter
Product family name OPTIFLUX
Product positioning For standard applications with abrasive and aggressive liquids
Measurement principle Electromagnetic
Measured media Liquids

Operating conditions

Process pressure max. 40 barg/
580 psig
Process temperature -40…+180°C/
-40…+356°F

Materials

Liner Perfluoroalkoxy alkane (PFA), Polytetrafluoroethylene (PTFE), Polyuretane (PUR), Hard rubber, Ethylene tetrafluoroethylene (ETFE), Soft rubber

Process connections

Flange connections EN (1092-1): DN2.5…1200
ASME (B 16.5): ⅒…48″
JIS (B 2220): 2.5…1000A

Approvals/Standards

Certificates/Approvals Ex ATEX, IECEx, NEPSI, FM, CSA
Certificates/Approvals Hygienic FDA
Certificates/Approvals Marine ABS, BV, CCS, DNV, KR, LR, NK, RINA, CRS, IRS, PRS, RS

Communication

Analogue outputs 4…20 mA
Discrete outputs Pulse, Frequency, Status
Digital outputs HART®



Datasheet: PDF
