KEYENCE Diffuse Reflective Sensor PR-G41CBL
- Output: NPN+PNP
- Connection: M12 (4 Pin)
- Sensing Distance: 500 mm
Description
KEYENCE Diffuse Reflective Sensor PR-G41CBL
M18 Threaded type diffuse reflective M12 Connector Type, 500 mmPR-G41CBL
KEYENCE PR-G41CBL
The PR-G Series is a heavy duty general purpose photoelectric sensor in a metal housing with high power and easy trimpot adjustment. It has a range of up to 30m (98.4′) and offers hard wired, M8 connector, and M12 connector cable options.
Specifications
|
Model |
PR-G41CBL | |||
| Type | Diffuse reflective (Long distance) | |||
| Shape | Threaded mount type | |||
| Output | NPN+PNP | |||
| Cable connection | M12 connector (4 pin) | |||
| Detecting distance | 500 mm19.685″ | |||
| Number of control outputs | 2 (NPN+PNP) | |||
| Output operation | Output 1 | Light-ON | ||
| Output 2 | Dark-ON*1 | |||
| Response time | 0.5 ms | |||
| Sensitivity adjustment | Five-turn trimmer | |||
| Spot diameter | ø20 mm ø0.79″ max. (at 300 mm 11.81″) |
|||
| Light source | 4 elements, Point light source red LED (650 nm) | |||
| Light interference prevention function | 2 | |||
| Indicator lamp | 7 segment display (0 to 999), output indicator (yellow) | |||
| Control output | NPN + PNP open collector 30 VDC or less, 100 mA or less Residual voltage: 1.2 V or less at less than 10 mA, 2 V or less at 10 to 100 mA |
|||
| Stop emission input | ― | |||
| Protection circuit | Protection against reverse power connection, power supply surge, output overcurrent, output surge, and reverse output connection | |||
| Rating | Power voltage | 10 to 30 VDC, including Ripple (P-P) 10 % | ||
| Power consumption | 450 mW max. (15 mA max. at 24 V, 21 mA max. at 12 V) | |||
| Environmental resistance | Enclosure rating | IP68 (IEC60529), IP69K (DIN40050-9), 4, 6, 13 (NEMA250)*2 | ||
| Insulation resistance | 20 MΩ or more (500 VDC) | |||
| Ambient light | Incandescent lamp: 5,000 lux or less, Sunlight: 20,000 lux or less | |||
| Ambient temperature | -20 to +70 °C -4 to 158 °F (No freezing)*3 | |||
| Relative humidity | 35 to 85 % RH (No condensation) | |||
| Storage temperature | -20 to +70 °C -4 to 158 °F | |||
| Withstand voltage | 1,000 VAC, 50/60 Hz, 1 min | |||
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions | |||
| Shock resistance | 1,000 m/s2, 6 times in each of the X, Y, and Z directions | |||
| Accessories | Instruction Manual, M18 nut, Lock washer | |||
| Weight | Approx. 45 g | |||
| *1 Output 2 is not available on the threaded mount type or M8 3-pin type. *2 For the connector type, the enclosure rating varies depending on the cable that is used. *3 When the ambient temperature is 60 °C 140 °F or higher, the device should be powered with no more than 24 VDC and 50 mA. |
||||
