KEYENCE Photoelectric Sensors | PR-G51CBD
- Functional principle: Thrubeam
- Sensing range (max.): 30 m 98.43′
- Connection type: M8 connector (4 pin)
- Output Type: PNP+NPN
- Light type: 4 elements, Red LED (631 nm)
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
KEYENCE Photoelectric Sensors | PR-G51CBD
KEYENCE Photoelectric Sensors
KEYENCE Photoelectric Sensors Supplier in Bangladesh
PR-G
Self-contained Photoelectric Sensor
The PR-G Series is a heavy duty general purpose photoelectric sensor in a metal housing with high power and easy trimpot adjustment. It has a range of up to 30m (98.4′) and offers hard wired, M8 connector, and M12 connector cable options.
PR-M/F AT A GLANCE
- New Standard for Photoelectric Sensors: KEYENCE is known for durable sensors and PR-G is one of the most durable.
-
High Power: The PR-G Series has options powerful enough to blast 30m (98.4′). This power also benefits shorter range applications by being able to blast through dust, dirt, oil, etc.
- Ease of Use: A simple trimpot is used to adjust the sensitivity on all PR-G sensors. This series also features highly visible output indicators and options that have a digital display, providing real-time feedback.
Technical details-
| Property | Value |
| Model | PR-G51CBD |
| Type | Thrubeam |
| Shape | Threaded mount type |
| Output | NPN+PNP |
| Cable connection | M12 connector (4 pin) |
| Detecting distance | 30 m 98.43′ |
| Number of control outputs | 2 (NPN+PNP) |
| Output operation (Output 1) | Dark-ON |
| Output operation (Output 2) | Light-ON*1 |
| Response time | 1 ms |
| Sensitivity adjustment | One-turn trimmer (230°) |
| Spot diameter | ― |
| Light source | 4 elements, Red LED (631 nm) |
| Light interference prevention function | ― |
| Indicator lamp |
Transmitter: power supply indicator (green)
Receiver: output indicator (yellow), Stable operation indicator (green) |
| Control output |
NPN + PNP open collector 30 VDC or less, 100 mA or less Residual voltage: 1.2 V or less at less than 10 mA, 2 V or less at 10 to 100 mA |
| Stop emission input |
Non-voltage input Input time ON: 1 ms or more, OFF: 20 ms or more |
| Protection circuit | Protection against reverse power connection, power supply surge, output overcurrent, output surge, and reverse output connection |
| Power voltage | 10 to 30 VDC, including Ripple (P-P) 10 % |
| Power consumption |
Transmitter: 450 mW max. (15 mA max. at 24 V, 15 mA max. at 12 V) Receiver: 360 mW max. (12 mA max. at 24 V, 12 mA max. at 12 V) |
| Enclosure rating | IP68 (IEC60529), IP69K (DIN40050-9), 4, 6, 13 (NEMA250)*2 |
| Insulation resistance | 20 MΩ or more (500 VDC) |
| Ambient light | Incandescent lamp: 5,000 lux or less, Sunlight: 20,000 lux or less |
| Ambient temperature | -20 to +70 °C -4 to 158 °F (No freezing)*3 |
| Relative humidity | 35 to 85 % RH (No condensation) |
| Storage temperature | -20 to +70 °C -4 to 158 °F |
| Withstand voltage | 1,000 VAC, 50/60 Hz, 1 min |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 1,000 m/s2, 6 times in each of the X, Y, and Z directions |
| Accessories | Instruction Manual, M18 nut, Lock washer |
| Weight | Approx. 85 g |
*1 Output 2 is not available on the threaded mount type or M8 3-pin type.
*2 For the connector type, the enclosure rating varies depending on the cable that is used.
*3 When the ambient temperature is 60 °C 140 °F or higher, the device should be powered with no more than 24 VDC and 50 mA.
*4 For the threaded mount type sensors, the outputs are 1 NPN output and 1 PNP output.
Datasheet: PDF
