KEYENCE Inductive Proximity Sensors | EV-130U
- Sensing range (max.): 27 mm 1.06″ ±10%
- Output function: NO
- Switching frequency: 250 Hz
- Installation type: Non Shielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
KEYENCE Inductive Proximity Sensors | EV-130U
KEYENCE Inductive Proximity Sensors
KEYENCE Inductive Proximity Sensors Supplier in Bangladesh
EV
Two-wire self contained amplifier proximity sensors
- Compact sensor head
- Visible output indicator built into sensor
- Flexible cable joint
- IP67-rated housing
Technical details-
| Property | Value |
| Model | EV-130U |
| Type | DC , Non-shielded |
| Shape | M30 |
| Detecting distance | 27 mm 1.06″ ±10% |
| Detectable object | Ferrous metals (see Characteristics for nonferrous metals) |
| Standard target (iron, t=1 mm 0.04″) | 70 x 70 mm 2.76″ |
| Hysteresis | 20% max. of detecting distance, within -10 to +70°C 14 to 158°F |
| Response frequency | 250 Hz |
| Operation mode | N.O. |
| Temperature characteristics | -5 to +20%, within -10 to +70°C 14 to 158°F |
| Control output (switching capacity) | 5 to 200 mA |
| Protection circuit | Reversed polarity, short-circuit, surge voltage |
| Cable length | 2 m 6.6′ |
| Power voltage | 12 to 24 VDC, Ripple (P-P) 20 % or less |
| Current consumption (leakage current) | 1.0 mA max., Residual voltage: 3.6 V max. (with 2-m 6.6′ cable) |
| Residual voltage | 3.6 V max. (with 2-m 6.6′ cable) |
| Enclosure rating | IP67 |
| Ambient temperature | -25 to +80 °C -13 to 176 °F (No freezing) |
| Relative humidity | 35 to 95 % RH (No condensation) |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 1,000 m/s2, 3 times in each of the X, Y, and Z directions |
| Case material | Nickel-plated brass |
| Accessories | Nut × 2, toothed washer × 1, instruction manual |
| Weight | Approx. 260 g |
Datasheet: PDF
