KEYENCE Photoelectric Sensors | LR-TB2000C
- Sensing range (max.): 60 to 2000 mm 2.36″ to 78.74″
- Connection type: Cable with connector M12
- Output Type: NPN/PNP
- Output function: NO/NC selectable
- Light type: Red laser (660 nm)
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
KEYENCE Photoelectric Sensors | LR-TB2000C
KEYENCE Photoelectric Sensors
KEYENCE Photoelectric Sensors Supplier in Bangladesh
LR-T
Laser Sensor with 0.06 – 5m Range and Stable Detection Regardless of Target
The LR-T Series detects objects based on position and offers extended range to allow for flexible mounting. It is housed in a rugged metal housing, has a simple one button teach and is unaffected by color, surface finish or angle. This series has a range of up to 5m (16.4′) and offers hard wired and M12 connector cable options.
LR-T AT A GLANCE
-
Superior Detection Capabilities: The LR-T is designed to detect at long ranges while remaining highly stable. This is achieved due to the HS2 technology used, a combination of Time of Flight detection and a custom integrated circuit. Additionally, the interference prevention and Datum Function allow users to maximize this sensors capability in any situation.
-
Easy to Use: The LR-T Series is simple to install and calibrate. Flexible mounting options, a visible beam spot, push button teach, and an easy to read display allow for quick setup. Even at long distances, constant feedback is provided with the LR-T’s highly visible status indicator.
-
Unmatched Versatility: The 5m (196.85”) range of the LR-T allows the sensor to be mounted away from operators or machinery keeping it out of harm’s way. Furthermore, an adjustable beam spot allows users to fine-tune the sensor from any distance.
-
Product Applications: A large variety of applications are possible with the LR-T. Examples include level sensing, web tension control, and general conveyance detection.
-
Increased Accessibility with Easily Attachable Controller: The MU-N Series controller provides a remote display that can be used to quickly calibrate and easily monitor attached sensors. This controller pairs perfectly with the LR-T Series, which can be mounted further from targets and in potentially hard to reach positions, due to its long range detection capabilities.
Technical details-
| Property | Value |
| Model | LR-TB2000C |
| Type | Cable with connector M12 |
| Detectable distance | 60 to 2000 mm 2.36″ to 78.74″*1 |
| Spot diameter | Approx. ø4 mm ø0.16″ |
| Light source type | Red laser (660 nm) |
| Laser class | Class 2 laser product (IEC60825-1,FDA (CDRH) Part1040.10*2) |
| Mutual interference prevention function | 4 units (when using the interference prevention function) |
| Timer | OFF/OFF delay/ON delay/One-shot |
| Response time | 1 ms/10 ms/25 ms/100 ms/1000 ms selectable |
| Control output |
NPN open collector/PNP open collector selectable 30 VDC or less, 50 mA or less, residual voltage: 2 V or less, N.O./N.C. selectable 34 |
| Analog output | – |
| Protection circuit | Protection against reverse power connection, power supply surges, output overcurrent, reverse output connection, and output surge |
| Power voltage | 20 to 30 VDC, including 10% ripple (P-P), Class 2 or LPS |
| Current consumption | 45 mA or less (without load)*5 |
| Enclosure rating | IP65/IP67 (IEC60529) |
| Ambient light | Incandescent lamp/Sunlight: 10,0000 lux or less |
| Ambient temperature | -20 to +55 °C -4 to 131 °F (No freezing) |
| Relative humidity | 35 to 85 % RH (No condensation) |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 1,000 m/s2, 6 times in each of the X, Y, and Z directions |
| Material | Case: Zinc die cast (Nickel chrome plating), Indicator cover and buttons: PES, Lens cover and display: PMMA (scratch-resistant coating specifications), Cable bushing: PBT, Cable: PVC, M12 connector: TPE, PBT, Nickel-plated brass |
| Accompanying items | Instruction manual, Laser warning and explanation labels |
| Weight | Approx. 85 g |
*1 The range for displayable distance is from 50 to 2200.
*2 The laser classification for FDA (CDRH) is implemented based on IEC60825-1 in accordance with the requirements of Laser Notice.
*3 You can select the I/O from the following combinations.
Control output × 2, control output + external input
Control output + analog output (LR-TB5000/TB5000C/TB5000CL only)
External input + analog output (LR-TB5000/TB5000C/TB5000CL only)
(For details on the setting method, see the instruction manual.)
*4 IO-Link specification v.1.1/COM2 (38.4 kbps) is supported. You can download a setup file from the KEYENCE website (http://www.keyence.com).
If you are using the product in an environment in which you cannot download files over the Internet, contact your nearest KEYENCE office.
*5 145 mA or less (with load)
*6 The range for displayable distance is from 50 to 5200.
*7 150 mA or less(with load)
Datasheet: PDF
More Photoelectric sensors :
KEYENCE LR-TB2000, KEYENCE LR-TB2000CL, KEYENCE LR-TB5000, KEYENCE LR-TB5000C, KEYENCE LR-TB5000CL
