KEYENCE Inductive Proximity Sensors | ED-130U
- Sensing range (max.): 20 mm 0.79″ ±15%
- Output function: NO
- Output type: NPN
- Switching frequency: 150 Hz
- Installation type: Non Shielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
KEYENCE Inductive Proximity Sensors | ED-130U
KEYENCE Inductive Proximity Sensors
KEYENCE Inductive Proximity Sensors Supplier in Bangladesh
ED
Built-in Amplifier Proximity Sensor for Non-ferrous Metals
Long-distance detection of non-magnetic metals such as aluminum
Technical details-
| Property | Value |
| Model | ED-130U |
| Type | Non-shielded |
| Shape | M30 Threaded type |
| Detecting distance | 20 mm 0.79″ ±15% |
| Detectable object | All metals *1 |
| Standard target (aluminum, t=1 mm 0.04″) | 70 x 70 mm 2.76″ |
| Hysteresis | 15% max. of detecting distance |
| Response frequency | 150 Hz |
| Operation mode | N.O. |
| Indicator lamp | Operation indicator: Red LED, Stable operation indicator: Green LED |
| Temperature characteristics | ±20% max. of detecting distance at 23°C 73.4°F, within 0 to 50°C 32 to 122°F |
| Control output | NPN open collector 100 mA max. (40 V max.), Residual voltage: 1 V max. |
| Protection circuit | Reversed polarity, surge absorber |
| Power voltage | 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less |
| Current consumption | 35 mA or less |
| Enclosure rating | IP67 |
| Ambient temperature | 0 to +50 °C 32 to 122 °F (No freezing) |
| Relative humidity | 35 to 95 % RH (No condensation) |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 1,000 m/s2, 3 times in each of the X, Y, and Z directions |
| Case material | Nickel-plated brass |
| Accessories | Screw nut x 2, toothed washer x 1 |
| Weight | Approx. 270 g (including 2-m 6.6′ cable and nuts) |
Datasheet: PDF
