Honeywell Valve Actuator CN7510A2001
- 10Nm,
- 24Vac/Vdc
- Modulating control
- Non-Spring return Voltage Feedback Signal and without aux
- Switch
Description
Honeywell Valve Actuator CN7510A2001
Honeywell Valve Actuator
Product Details:
| Product | Description |
|---|---|
| Brand | Honeywell |
| Model | CN7510A2001 |
| Power consumption | 5 VA / 2 W |
| Supply voltage | 24 Vac/dc -15%/+20%, 50/60 Hz |
| Nominal voltage | 24 Vac/dc, 50/60 Hz |
| Control signal | Modulating (0)2…10 Vdc
Floating/2-Position 24 Vac/dc |
| Ambient limits | Ambient operating limits :-20…+60 °C(-5…+140 °F )
Ambient storage limits : -30…+80 °C(-22…+176 °F ) Relative humidity: 5…95% |
| Protection standard | IP54 |
| Lifetime | Full strokes 60000
Repositions 1.5 million |
| Mounting | Round damper shaft 3/8 in…5/8 in.
Square damper shaft 1/4 in…1/2 in.; 45° steps Shaft length min. 1-5/8 in. |
| Torque rating | 44 lb-in. (5Nm) / 88 lb-in. (10Nm) |
| Rotation stroke | 95° + 3° |
| Weight (without cables) | 1.0 lbs. |
| Certification | CE & UL |
Honeywell Valve Actuator
Data Sheet: PDF
