Honeywell VersaFlow Coriolis 200 Flowmeter

Honeywell VersaFlow Coriolis 200 Flowmeter

Industries

• Oil & Gas

• Water & Wastewater

• Chemical & Petrochemical

• Paper &Pulp

• Pharmaceutical



For Price Call: 01329727092
Email: sales@voltecbd.com
Categories: ,
Tags:

Description

Honeywell VersaFlow Coriolis 200 Flowmeter

Honeywell Bangladesh Supplier / Honeywell Flowmeter supplier in Bangladesh



The Solution for Bulk Mass Flow Measurement

The VersaFlow Coriolis 200 has been developed to meet the demanding requirements of the oil and gas industry and is well suited to bulk measurement in many applications. The option of Super Duplex (UNS S32760) provides a maximum operating pressure of 180 barg. A high level of performance makes the VersaFlow Coriolis 200 suitable for the bulk measurement of petroleum and oil as well as products like syrup, molasses, and raw chemicals. Combined with the power of the TWC9400, the VersaFlow Coriolis 200 will provide accurate measurement of mass, volume, density and concentration.



Processing & Performance Metrics

  • Accuracy
  • ±0.05% (Optional, not in SIL Mode) (Liquid)
  • ±0.1% of Actual Measured Flow Rate (standard)
  • ±0.35% of Actual Measured Flow Rate + Zero Stability (Gas)
  • Zero Stability
  • As low as ±0.004% of max flow (Titanium, 1000), ±0.01% (100), see model for details
  • Maximum Flow Rate
  • Up to 170,000 kg/h (Coriolis 100) gallons per minute
  • Up to 420,000 kg/h (Coriolis 200) gallons per minute
  • Up to 550,000 kg/h (Coriolis 6000) gallons per minute
  • Up to 560,000 kg/h (Coriolis 1000) gallons per minute

Material Specifications

  • Tube Material
  • Stainless Steel, Hastelloy®, Titanium, Tantalum, Super Duplex (model dependent)

Environmental Conditions

  • Temperature Range
  • Coriolis 100: -40 to +130 deg C, Coriolis 1000: -40 to +150 deg C (Ti), 0 to +100 deg C (SS), Coriolis 200: -45 to +130 deg C, Coriolis 6000: -200 to +400 deg C (extended)
  • Nominal Pressure
  • Up to 100 barg (others) bar (air pressure)
  • Up to 180 barg (Coriolis 200, Super Duplex) bar (air pressure)
  • Up to 200 barg (Coriolis 6000, Hastelloy) bar (air pressure)
  • Ambient Temperature Range
  • -40 to +55 deg C (Compact Stainless Steel)
  • -40 to +65 deg C (Remote)
  • -40 to +65 deg C (Standard, Compact Aluminum)

Overview

  • Sensor Models
  • Coriolis 100 (General Purpose, Twin Tube), Coriolis 1000 (Straight Tube, High Purity/Chemicals), Coriolis 200 (Bulk, Large Diameter, Oil and Gas), Coriolis 6000 (Twin V-Tube, Extended Temp, Cryogenic)

Functional & Control Features

  • Self-Diagnostics
  • NAMUR NE107, Advanced Diagnostics, Entrained Gas Management (EGM), Redundant Calibration

Measurement & Sensor Related (Measurement Capabilities)

  • Repeatability
  • Liquid: better than 0.05% + zero stability, Gas: better than 0.2% + zero stability
  • Measured Variables
  • Mass Flow, Density, Temperature (Direct)
  • Volume, Concentration, Velocity (Calculated)
  • Converter
  • TWC9400 (compact or remote, Ex/non-Ex, HART/Modbus)

Standards & Certifications

  • Protection Category
  • IP67 (NEMA 4X) (All models)
  • Approvals
  • CE Mark with PED, FM/CSA (Class I/II/III Div 1/2), IECEx, ATEX, OIML R117-1 (Custody Transfer), NACE, CRN

Technical Specifications

  • Process Connections
  • Flanges: DIN, ASME, JIS (various ratings), Hygienic: Tri-clamp, DIN 32676, ISO 2852, DIN 11864-2, SMS, IDF/ISS, RJT (model dependent)
  • Density Measuring Range
  • 100 to 3000 kg/m³ (6000), 400 to 2500 kg/m³ (100/1000)

I/O Capabilities

  • Outputs/Comms
  • Current (Active/Passive, HART®), Pulse, Frequency, Status, Modbus, Limit Switch, Control Input
  • Installation
  • Can be mounted at angle, horizontal, or vertical (prefer uphill flow)
  • No straight runs required

Electrical Specifications

  • Nominal Sizes
  • Coriolis 100: DN15 to DN50 (1/2 to 2 in), Coriolis 1000: DN04 to DN80 (1/8 to 3 in), Coriolis 200: DN100 to DN150 (4 to 6 in), Coriolis 6000: DN08 to DN200 (3/8 to 8 in)

Applications & Compatibility

  • Mounting
  • Compact (Integral Converter) or Remote (Field/Wall/Rack Mount, up to 300 m Cable)
  • Applications
  • Bulk Loading/Unloading, Custody Transfer, Pipeline Measurement, Allocation Metering, Viscous/Cryogenic Fluids, Slurries, Highly Corrosive Fluids, Products With Entrained Solids/Gas

Industries / Applications & Compatibility

  • Industries
  • Oil and Gas, Chemical, Petrochemical, Water and Wastewater, Food and Beverage, Pharmaceutical, Power, Mining

Software & Interface

  • Display
  • Graphic LCD, Backlit, Rotatable, Pushbutton/Optical Keys, IR Interface



Datasheet: PDF
