DANFOSS HVAC Drive FC 102 series 11 KW | 131B1274
- Power Rating: (P11K) 11 KW / 15 HP
- Phase: Three phase
- Operating voltage: 380 – 480 VAC
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
DANFOSS HVAC Drive FC 102 series 11 KW | 131B1274
DANFOSS HVAC Drive
DANFOSS HVAC Drive Supplier in Bangladesh
DANFOSS HVAC Drive AT A GLANCE
Danfoss VLT® HVAC Drive FC-102 Drive is dedicated to ventilation, heating, and refrigeration applications. With a wide range of powerful standard and optional features, the Drive provides the lowest overall cost of ownership.
Technical Details
| Gross weight | 24.71 Kilogram | ||
| Net weight | 21.09 Kilogram | ||
| Volume | 105.71 Liter | ||
| EAN | 5702427209367 |
| Product Group | FC- | VLT® HVAC Drive FC- | |
| Series | 102 | 102 | |
| Power Rating | P11K | (P11K) 11 KW / 15 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 4 | 380 – 480 VAC | |
| Enclosure | P55 | IP55 / Type12 Backplate | |
| RFI Filter | H2 | RFI Filter | |
| Brake – Safe Stop | X | No brake chopper | |
| LCP | G | Graphical Loc. Cont. Panel | |
| Coating PCB | X | Not coated PCB | |
| Mains Option | X | No Mains Option | |
| Adaptation A | X | Standard Cable Entries | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Software Language Pack | X | Standard Language Pack | |
| A Option | AX | No A Option | |
| B Option | BX | No B Option | |
| C0 Option MCO | CX | No C0 option | |
| C1 Option | X | No C1 option | |
| C Option Software | XX | No software option | |
| D Option | DX | No D option | |
| Frame Size | B1 | B1 | |
| Height [mm] | 494,0 | 494,0 | |
| Width w/ no C options [mm] | 243,0 | 243,0 | |
| Depth [mm] | 261,0 | 261,0 | |
| Depth with Option A/B [mm] | 261,0 | 261,0 | |
| Product Catalog | NO_VIEW | NO VIEW | |
| Modelcode01 | FC-102P11KT4P55H2XGX | ||
| Modelcode02 | XXXSXXXXAXBXCXXXXDX | ||
| Power 110% (NO) [KW] | 11 | 11 | |
| kVA | 16.6 | 16.6 | |
| Power Loss NO [W] | 278 | 278 | |
| Power Loss NO [W] | 278 | 278 | |
| Continuous Current (NO) [A] | 24 | 24 | |
| Intermittent Current (NO) [A] | 26.4 | 26.4 | |
| Continuous Current (NO) [A] | 21 | 21 | |
| Intermittent Current (NO) [A] | 23.1 | 23.1 | |
| Calculated Gross Weight [kg] | 24.71 | ||
| Calculated Net Weight [kg] | 21.09 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a |
Datasheet: PDF
