DANFOSS 132L1975

DANFOSS Midi Drive FC 280 series 0.55 kW | 132L1975

  • Power Rating: 0.55 kW / 0.75 HP
  • Phase: Three phase
  • Operating voltage: 380-480 VAC



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

DANFOSS Midi Drive FC 280 series 0.55 kW | 132L1975

DANFOSS Midi Drive

DANFOSS Midi Drive Supplier in Bangladesh

DANFOSS Midi Drive AT A GLANCE

The FC 280 does not include an LCP display or Memory Module. The LCP and the Memory Module can be ordered as an Accessory.

Technical Details

Gross weight 2.8 Kilogram
Net weight 2.5 Kilogram
Volume 16.53 Liter
EAN 5714853413119

Product Group FC- VLT® Midi Drive FC-
Series 280 280
Power Size PK55 0.55 kW / 0.75 HP
Voltage T4 Three phase 380-480 VAC
Enclosure E20 IP20 / Chassis
RFI Filter H1 EMC Cat C1(200V)/C2(400V)
Brake & Stop B Brake chopper
Display X No display
Coating C Coated PCB
Mains Option X No mains options
Adaptation A X No Adaption
Adaptation B X No Adaption
Special Version SFS1 Funct. Safety over com
Software Language Pack X Standard language pack
Control Card AL Integrated PROFINET
Frame Size K1 K1
Height [mm] 210.0 210.0
Width w/ no C options [mm] 75.0 75.0
Depth [mm] 168.0 168.0
Modelcode01 FC-280PK55T4E20H1BXC
Modelcode02 XXXSFS1XAL
Product Catalog NO_VIEW NO VIEW
Calculated Gross Weight [kg] 2.8
Calculated Net Weight [kg] 2.5
Continuous Current (HO) [A] 1.7 1.7
Intermittent Current (HO) [A] 2.7 2.7
Continuous Current (HO) [A] 1.6 1.6
Intermittent Current (HO) [A] 2.7 2.7
Power Loss HO [W] 25.2 25.2
kVA 1.2 1.2
Power 160% (HO) [KW] 0.55 0.55
ECCN EU Y901 Y901
ECCN US 3A999.a 3A999.a



Datasheet: PDF
